纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-022) - HYD LINES, UPP (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
122 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW03H00038F1 | [1] | HYD LINES, UPP | |
| 1. | PA30V00005F1 | [1] | VALVE | KOBASSY, SELECTOR |
| 1-1. | PA30V01011P1 | [1] | BODY | KOB |
| 1-2. | PA30V01012P1 | [1] | SHAFT | KOB |
| 1-3. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 1-4. | ZD75G02500 | [1] | BACK-UP RING | KOB |
| 1-5. | ZD85P02100 | [1] | RING | KOB |
| 1-6. | ZD12P02100 | [2] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOB |
| 1-7. | ZR16X02500 | [1] | RING | KOBRETAINING |
| 1-8. | ZS28C06010 | [1] | CAPSCREW,Hex Socket Head, M6 x 10mm | KOBSCREW CAP |
| 2. | HH25S08006G2 | [2] | HYD CONNECTOR | KOB Superseded by part number: 72284893 |
| 2-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 4. | HH35S08006G1 | [1] | 90 ELBOW | KOB |
| 5. | HH45S08006G1 | [2] | 45 ELBOW | KOB |
| 8. | HX35L08060DX | [1] | HOSE | KOBHOSE |
| 9. | HX32L08042DX | [1] | HOSE,12.7mm ID x 420mm L | KOB |
| 10. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOB |
| 11. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
