纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-024) - CONTROLS, OPERATORS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
362 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW03M00092F1 | [1] | CONTROLS, OPERATORS | |
| 1. | PW03M00093F1 | [1] | CONTROL BOX ASSY, SEE FIG 01-027 | |
| 2. | PW03M01448P3 | [1] | BOX | KOBCONTROL BOX |
| 3. | YT17M01034P2 | [1] | HOLDER | KOB |
| 4. | YT02C01296P1 | [2] | RIVET | KOB |
| 5. | ZW16X06000 | [2] | WASHER | KOB Superseded by part number: 86588450 |
| 6. | YT58S00006P1 | [1] | HOURMETER | KOBHOUR |
| 7. | ZM22C10030 | [3] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| 8. | ZM22C08020 | [4] | BOLT | KOB |
| 9. | PW03M01319P1 | [2] | BOLT | KOB |
| 10. | PW03M01717D1 | [6] | BOLT,Torx, Truss HD, M5 x 0.8 x 16mm | KOB |
| 11. | PV24E01001P2 | [1] | SWITCH | KOB |
| 12. | 2414T4530 | [4] | CAP | KOB |
| 13. | PW17M01020P1 | [1] | LABEL | KOB |
| 14. | PH59S00005F1 | [1] | GAUGE ASSY. | KOBCLUSTER, FIG 01-057 |
| 15. | ZS32T40016 | [4] | SCREW | KOBCROSS TAPPING |
| 16. | ZW16K04000 | [4] | WASHER | KOBWASHER |
| 17. | PW17M01021P1 | [2] | CAP | KOB |
