纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-026) - GRIP ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
305 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW03M01719F1 | [1] | GRIP ASSY | |
| A1. | YB03M01003F1 | [1] | GRIP | KOBASSY (R.H.) |
| A1-1. | LF03M01005F1 | [1] | HANDLE | KOB(With 1 Switch) |
| A1-3. | YB03M01002P1 | [1] | LEVER | KOB |
| A1-4. | ZP26D05028 | [1] | PIN,5mm OD x 28mm L, Slotted | KOBSPRING |
| A2. | YB03M01003F2 | [1] | GRIP | KOBASSY (L.H.) |
| A2-2. | LF03M01005F3 | [1] | HANDLE | KOB(With 3 Switches) |
| A3. | LF03M01004P1 | [2] | BOOT | KOB |
| A4. | LF03M01008P1 | [2] | BELLOWS | KOB |
| A5. | YT03M01051P2 | [2] | PLATE | KOB |
| A6. | ZN18C14011 | [2] | NUT | KOB |
| . . | PW03M01718F1 | [1] | SUPPORT | KOBSUPPORT ASSY |
| B1. | PW03M01745P1 | [1] | SUPPORT | KOB |
| B2. | PW03M01746P1 | [1] | SUPPORT | KOB |
| B3. | PV03M01135P1 | [2] | SPACER | KOB |
