纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-036) - CONTROL LINES, VALVE, P/N PW64H00053F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
907 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2444Z2894 | [5] | 90 ELBOW | KOB |
| 2. | HH45S04004G1 | [4] | 45 ELBOW | KOB |
| 3. | HH35S04004G1 | [3] | 90 ELBOW | KOB |
| 4. | HH35S04004G2 | [1] | ELBOW | KOB |
| 5. | GB50S00049F2 | [2] | SWITCH | KOBPRESS (L.P.) |
| 6. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| 7. | 2444Z4239 | [1] | TEE | KOB |
| 8. | HH25S04004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: 72283606 |
| 9. | PE35V00001F2 | [1] | SOLENOID VALVE | KOBVALVE ASSY, SOLENOID |
| 10. | HX33L03145DX | [1] | HOSE,4.8mm ID x 1450mm L | KOB |
| 11. | HX33L03170DX | [1] | HOSE | KOBHOSE |
| 12. | HX23L03180DX | [1] | HOSE | KOBHOSE |
| 13. | HX23L03155DX | [1] | HOSE | KOBHOSE |
| 14. | HX24L04030DX | [1] | HOSE | KOB |
| 15. | HX22L04030DX | [1] | HOSE | KOBHOSE |
| 16. | 2444Z3306 | [1] | ELBOW | KOB |
| 17. | 2444Z4231 | [1] | ELBOW | KOB |
| 18. | ZS28C10070 | [2] | SCREW,Hex Socket Head, M10 x 70mm | KOBCAP |
| 19. | ZW26K10000 | [2] | LOCK WASHER | KOB |
| 20. | ZW16H10000 | [1] | WASHER | KOB |
| 21. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 22. | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOB |
