纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-057) - GAUGE ASSY, CLUSTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
250 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PH59S00005F1 | [1] | GAUGE ASSY. | KOB |
| 1. | PH59S00005S001 | [1] | GAUGE ASSY. | KOB |
| 2. | PH59S00005S002 | [1] | GLASS | KOB |
| 3. | PH59S00005S003 | [1] | CASE | KOB |
| 4. | PH59S00005S004 | [1] | HARNESS | KOB |
| 5. | PH59S00005S005 | [1] | CLIP | KOB |
| 6. | PH59S00005S006 | [6] | SCREW | KOBMACHINE |
| 7. | PH59S00005S007 | [1] | SCREW | KOBMACHINE |
| 8. | PH59S00005S008 | [6] | LAMP | KOB |
| 9. | PH59S00005S009 | [1] | LAMP | KOB |
