纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-058) - BATTERY INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
521 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW72E00011F1 | [1] | BATTERY INSTAL | |
| 1. | PW72E00010F1 | [1] | BATTERY INSTAL | |
| 1-2. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 1-3. | ZW16H10000 | [2] | WASHER | KOBWASHER |
| 1-4. | PW72E01019P1 | [2] | ROD | KOB |
| 1-5. | PW72E01018P1 | [1] | PLATE | KOB |
| 1-6. | PW72E01017P1 | [1] | PLATE | KOB |
| 1-7. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 1-8. | ZW16X08000 | [2] | WASHER | KOB |
| 2. | F565DSW | [1] | WET BATTERY,12V, 700CCA | MKT |
| 2. | PW72500004P1 | [1] | BATTERY | |
