纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-059) - HEATER ASSY (WITH HEATER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
672 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW21M00013F1 | [1] | HEATER ASSY | |
| 1. | R18T0026D57 | [1] | HOSE | KOB |
| 2. | PM21M00005F1 | [1] | HEATER ASSY. | KOBComponents are NSS, Includes Blower Motor |
| 3. | PW03M01461P1 | [1] | GROMMET | KOB |
| 5. | ZC16X02000 | [4] | CLIP | KOB |
| 6. | R18T0026D59 | [1] | HOSE | KOB |
| 7. | YN20M01046DW | [2] | TUBE,22.10mm ID x 27.00mm OD x 710.00mm | KOBProtective Plastic |
| 8. | 2444Z1630 | [2] | FITTING | KOBCONNECTOR |
| 9. | PM21M01018P1 | [1] | ELBOW | KOB |
| 10. | PY50S00003P2 | [1] | SWITCH | KOB |
| 11. | PV01P01007P1 | [4] | WASHER | KOB |
| 12. | ZM11C08016 | [4] | BOLT | KOBSEMS |
| 13. | PW17M01019P1 | [1] | LABEL | KOB |
| 15. | PA03M01093D2 | [14] | BOLT | KOBSEMS Superseded by part number: ZM27C08020 |
| 17. | PM22C01013DB | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 18. | 2420R429D4 | [2] | GROMMET | KOB |
| 20. | PW10M01277F1 | [1] | COVER ASSY | KOBCOVER ASSY |
| 20-1. | PW10M01278P1 | [1] | COVER | KOBCOVER |
| 20-2. | PW10M01242P1 | [1] | INSULATION | KOBINSULATION |
| 21. | YN03E01001D5 | [2] | CLIP | KOB |
| 22. | PW13E01068P1 | [1] | HARNESS | KOB |
| 23. | PW03M01853P1 | [1] | COVER | KOBCOVER |
| 24. | PW10M01273P1 | [1] | COVER | KOBCOVER |
| 25. | PW21M01026P1 | [1] | RUBBER STRIP | KOBRUBBER |
| 26. | PW21M01027P1 | [1] | RUBBER STRIP | KOBRUBBER |
