纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (02-002) - RING ASSY, SLEWING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
655 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW40F00006F1 | [1] | RING ASSY, SLEWING | |
| 1. | PW40F00004F1 | [1] | RING ASSY. | KOBSLEWING Superseded by part number: PW40F00004F2 |
| 1-8. | PW40F00004S008 | [1] | SEAL | KOB |
| 2. | ZS18C12065 | [16] | SCREW,Hex, M12 x 65mm | KOBCAP |
| 3. | PW40F01001P1 | [1] | RING | KOBFRAME |
| 4. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
