神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (02-008) - PLATE ASSY, FLOOR (WRIST CONTROL TYPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3932F1 | [1] | PLATE ASSY, FLOOR | |
| 1. | 2418N2704 | [1] | PLATE, FLOOR | |
| 2. | 2427U409D1 | [1] | MAT, FLOOR | |
| 7. | 2414T2673 | [12] | COVER | KOBCOVER |
| 8. | 2416Z253D2 | [12] | RUBBER SLEEVE | KOBCUSHION, RUBBER |
| 9. | 2418T9226D5 | [6] | SPACER | KOB |
| 10. | ZS18C16100 | [6] | SCREW,Hex, M16 x 100mm | KOBM16x2.0x100mm |
| 11. | ZN32C16015 | [6] | NUT | KOBM16x2.0mm |
| 12. | ZW16H16000 | [12] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 13. | 2422T547 | [2] | STEP | |
| 14. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 15. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | 24100N3932F3 | [1] | PLATE ASSY, FLOOR | |
| 9. | 2418T9226D4 | [6] | SPACER | |
| 17. | 2418N2706 | [1] | PLATE, FLOOR | |
| 22. | 2427U424D1 | [1] | MAT, FLOOR | |
| . . | 24100N3932F7 | [1] | PLATE ASSY/ FLOOR | |
| 9. | 241819226D5 | [6] | SPACEW | |
| 26. | 2418N2710 | [1] | PLATE,FLOOR | |
| . . | 24100N3932F8 | [1] | PLATE ASSY/ FLOOR | |
| 27. | 2418N2711 | [1] | PLATE,FLOOR | |
