纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (03-007) - ARM ASSY, STD 1.32M (4FT 4IN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
136 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX12B00092F1 | [1] | ARM | KOBARM ASSY Superseded by part number: PX12B00093F1 |
| A1. | PX12B00093F1%N | [1] | ARM | KOBArm Assembly |
| A1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONARM |
| A1-1a. | PV12B01227P1 | [2] | BLOCK | KOB |
| A1-1b. | PX12B01185P1 | [2] | BLOCK | KOB |
| A1-1B. | PW12B01277P1 | [1] | PLATE | KOB |
| A1-2. | PW12B01237P2 | [2] | BUSHING,40mm ID x 82mm OD x 55mm L | KOB |
| A1-3. | PW12B01209P2 | [2] | BUSHING,45mm ID x 50mm OD x 31.5mm L | KOB |
| A1-4. | PX12B01177P2 | [2] | BUSHING,45mm ID x 55mm OD x 55mm L | KOB |
| A1-5. | PW12B01208D1 | [1] | COLLAR | KOB |
| A1-6. | PX12B01016P1 | [1] | COLLAR | KOB |
| . . | PX12B00109F1 | [1] | ARM INSTAL | |
| B2. | PX12B01320P1 | [1] | PIN,45mm OD x 160mm L | KOB |
| B3. | ZS18C16035 | [1] | SCREW,Hex, M16 x 35mm | KOBCAP |
| B4. | PW12B01242P1 | [1] | WASHER | KOB |
| B5. | ZW16H16000 | [1] | WASHER | KOB |
| B6. | YJ12B01097P1 | [1] | SHIM,47mm ID x 70mm OD x 0.5mm Thk | KOB |
| B7. | PR02B01121D1 | [1] | SHIM,47mm ID x 70mm OD x 0.9mm Thk | KOB |
| B8. | PW02B01239P1 | [1] | SHIM,0.5mm Thk | KOB |
| B9. | PW12B01243D1 | [1] | SHIM,0.5mm Thk | KOB |
| B10. | PW12B01243D2 | [2] | SHIM,0.9mm Thk | KOB |
| B11. | HS18C10085G2 | [1] | BOLT | KOBCAP |
| B12. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| . . | PX12B00072F1 | [1] | ARM GROUP | |
| C1. | PX12B01323F1 | [1] | LINK | KOBLINK ASSY, BUCKET Superseded by part number: PX12B01371F1 |
| C1-2. | PX12B01151P1 | [2] | BUSHING,40mm ID x 50mm OD x 50mm L | KOB |
| C1-3. | PX12B01246P1 | [2] | BUSHING,40mm ID x 50mm OD x 32mm L | KOB |
| C1-4. | PW12B01208D2 | [1] | COLLAR | KOB |
| C2. | PW12B01224P2 | [2] | LINK | KOB |
| C3. | PW12B01250P2 | [2] | PIN | KOBOD 35 x 280mm Long -- (Secures with Roll Pin PX61B01091P1) Superseded by part number: 87661259 |
| . . | PX61B01091P1 | [2] | PIN,10mm OD x 58mm L | KOBRoll (Used to secures Pin PW12B01250P2), Not Shown |
| C4. | PX12B01319P1 | [1] | PIN | KOB |
| C5. | PW12B01311P1 | [1] | PIN,40mm OD x 210mm L | KOB |
| C6. | ZS18C16030 | [2] | SCREW,Hex, M16 x 30mm | KOBCAP |
| C8. | PW12B01216P1 | [2] | WASHER | KOB |
| C9. | PN54D01001D3 | [10] | SEAL,40mm ID x 50mm OD x 4mm Thk | KOBDUST |
| C10. | 2445R138D20 | [2] | SEAL,45mm ID x 55mm OD x 4mm Thk | KOBDUST |
| C11. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| C12. | PR12B01113P1 | [4] | SHIM,0.5mm Thk | KOB |
| C13. | PR02B01123D1 | [4] | SHIM,0.9mm Thk | KOB |
| C14. | ZG91U02000 | [2] | LUBE NIPPLE | KOB |
