凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (18.87485072[03]) - DIA : ROLLER BALE CHUTE - SEASON 2009 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
768 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87485072
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
84801337
|
[1] |
ROLLER,108mm OD x 1127mm L
|
ZED
|
| 2. |
9837806
|
[2] |
FLANGED BEARING,25mm ID
|
ZED
|
| 3. |
84078290
|
[1] |
BRACKET
|
ZED
|
| 4. |
84164081
|
[1] |
SUPPORT
|
ZED
|
| 5. |
140046
|
[9] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 6. |
9706685
|
[9] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
140104
|
[2] |
WASHER,26mm ID x 45mm OD x 3mm Thk
|
ZED
|
| 8. |
120104
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 9. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 10. |
447336
|
[2] |
WASHER,11mm ID x 25mm OD x 3.99mm Thk
|
ZED
|
| 11. |
9706704
|
[1] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 12. |
84130682
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84213189
|
| 13. |
84130680
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84213193
|
| 14. |
84037242
|
[1] |
BUSHING
|
ZED
|
| 15. |
9706687
|
[8] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 16. |
43158
|
[1] |
BOLT,Hex, M12 x 80mm, Cl 8.8
|
NH
|
| 17. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
