纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-007[01]) - CONTROL LINES, REMOTE (COOLER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
846 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW64H00047F1 | [1] | CONTROL LINES, VALVE | |
| 2. | PH26V00001F1 | [1] | VALVE | KOBASSY, SHUTTLE |
| 5. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 6. | ZS18C06065 | [2] | SCREW,Hex, M6 x 65mm | KOBCAP |
| 7. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 8. | HH35S04004G1 | [6] | 90 ELBOW | KOB |
| 16. | HH55L04004G2 | [1] | TEE | KOB Superseded by part number: 72284852 |
| 20. | HH25S04004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: 72283606 |
| 21. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| 25. | HX33L03040DX | [1] | HOSE,4.8mm ID x 400mm L | KOB |
| 27. | HX33L03135DX | [1] | HOSE,4.8mm ID x 1350mm L | KOB |
| 28. | HX33L03145DX | [1] | HOSE,4.8mm ID x 1450mm L | KOB |
| 30. | HX23L03140DX | [1] | HOSE,4.8mm ID x 1400mm L | KOB |
| 40. | HH45S04004G1 | [1] | 45 ELBOW | KOB |
| 41. | ZW16H06000 | [4] | WASHER | KOB |
| 42. | YJ35V00004F2 | [1] | SOLENOID VALVE | KOBVALVE ASSY, SOLENOID |
| 44. | HX24L04028DX | [1] | HOSE | KOB Superseded by part number: HX24L04030DX |
| 45. | HX22L04028DX | [1] | HOSE,6.3mm ID x 280mm L | KOB |
| 46. | PH64H01053P1 | [1] | BRACKET | KOBBRACKET |
| 47. | HX34L04130DX | [1] | HOSE,6.3mm ID x 1300mm L | KOB |
| 48. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBCAP |
