纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-007[02]) - CONTROL LINES, REMOTE (COOLER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
402 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | PX35V00003F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 3. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMFILTER ASSY, INLINE |
| 4. | PW64H01072P1 | [1] | BRACKET | KOB |
| 8. | HH35S04004G1 | [1] | 90 ELBOW | KOB |
| 9. | 2444Z3326 | [1] | HYD CONNECTOR | KOBCONNECTOR Superseded by part number: 2444Z3744 |
| 10. | HH35S06006G1 | [1] | 90 ELBOW,90°, 3/8" PF x 3/8" PF x 60mm L | KOB |
| 11. | HH25S06006G1 | [2] | HYD CONNECTOR | KOB Superseded by part number: 124537A1 |
| 13. | ZE72X04000 | [1] | PLUG | KOB |
| 14. | ZE72X06000 | [3] | PLUG | KOB |
| 16. | HH55L04004G2 | [1] | TEE | KOB Superseded by part number: 72284852 |
| 17. | PW64H01011P1 | [1] | TEE | KOB |
| 18. | PH64H01057P1 | [1] | CONNECTION | KOB |
| 19. | YN64H01048P1 | [1] | TEE,90°, PF 3/8" x PF 3/8", O-Ring | KOB |
| 20. | HH25S04004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: 72283606 |
| 21. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| 23. | HX25L06135DY | [1] | HOSE,9.5mm ID x 1350mm L | KOB |
| 24. | HH55Q06006G1 | [1] | TEE | KOB |
| 26. | HX33L03110DX | [2] | HOSE,4.8mm ID x 1100mm L | KOB |
| 29. | HH25S04006G1 | [1] | HYD CONNECTOR | KOB |
| 32. | PW68H01023D9 | [1] | HOSE,9.5mm ID x 620mm L | KOB |
| 33. | ZC16X01800 | [1] | CLIP | KOB |
| 34. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 35. | ZW16H10000 | [2] | WASHER | KOB |
| 39. | HX33L03120DX | [1] | HOSE,4.8mm ID x 1200mm L | KOB |
| 43. | HH35S04004G2 | [1] | ELBOW | KOB |
