神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-013) - HEATER & DEFROSTER (FOR NORTH EUROPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
147 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6118F1 | [1] | HEATER AND DEFROSTER(FOR NORTH EUROPE) | |
| 1. | 24100P1066F2 | [1] | HEATER ASSY | |
| 1-1. | 2479U371 | [1] | HEATER | KOBSEE FIG 06-016 |
| 1-2. | 2416T10995 | [1] | BRACKET | BRACKET |
| 1-3. | 2406T1681 | [1] | LEVER | LEVER |
| 1-4. | 2418T10746 | [1] | PLATE | PLATE |
| 1-7. | 2432Z436 | [2] | CLAMP | CLAMP |
| 1-8. | 2406Z299D3 | [1] | CABLE | CABLE |
| 1-9. | 2406Z298D3 | [1] | CABLE | CABLE |
| 2. | 2444Z2158 | [2] | SOCKET | KOB |
| 3. | 2444Z2156D7 | [2] | HOSE | KOB |
| 4. | 2444Z2157 | [2] | SOCKET | KOB |
| 5. | 2427P1835 | [1] | DUCT, Serial Range: LC.2003-LC.2006 | DUCT, Serial Range: LC.2003-LC.2006 |
| 6. | 2444Z2220D3 | [2] | HOSE | KOB |
| 7. | ZC15X02300 | [4] | CLIP | KOB |
| 8. | 2418T10455 | [2] | PIPE | KOB |
| 9. | 2420Z699 | [1] | GROMMET | KOB |
| 10. | ZS18C10025 | [7] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZS16C06025 | [2] | SCREW | KOBM06x1.0x25mm Superseded by part number: ZS18C06025 |
| 12. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 13. | ZW26X10000 | [7] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 14. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 15. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 17. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 18. | 2432Z290 | [8] | CLIP | KOBWire Ties -- 185mm Long, Start Serial: LC.2007 Superseded by part number: PY01P01043D3 |
| 19. | R18T0026D21 | [1] | HOSE | KOBID 12 x OD 22 x 3450mm, Start Serial: LC.2007 |
| 20. | R18T0026D30 | [1] | HOSE | KOBID 12 x OD 22 x 3200mm, Start Serial: LC.2007 |
| 21. | R44T0180 | [1] | COCK | KOB, Start Serial: LC.2007 |
| 22. | R44T0201 | [1] | HYD CONNECTOR | KOB, Start Serial: LC.2007 Superseded by part number: 113700-1381 |
| 23. | R16T0238D1 | [2] | CLIP | KOB, Start Serial: LC.2007 |
| 24. | 2427P2572 | [1] | DUCT, Start Serial: LC.2007 | DUCT, Start Serial: LC.2007 |
| 25. | 2418T5373C2 | [3] | WASHER | KOBID 11 x OD 30 x Th 3.20mm, Start Serial: LC.2007 Superseded by part number: 2418T12346 |
