| . . | 24100X616F2 | [1] | CAB ASSY, CONSISTS OF REF 2 TO 21 | |
| 2. | 2427J628 | [1] | DOOR ASSY | |
| 3. | 2427J688 | [1] | FRAME, WINDOW | FRAME, WINDOW |
| 4. | 2427P1253 | [1] | FRAME, WINDOW | FRAME, WINDOW |
| 5. | 2427P1173 | [1] | WINDOW,RE. | |
| 6. | 2427P1172 | [1] | COVER | COVER |
| 7. | 2427Z248 | [2] | GLASS | |
| 8. | 2427Z288 | [2] | GLASS | |
| 9. | 2427Z289 | [1] | GLASS | |
| 10. | 2427Z290 | [1] | GLASS | |
| 12. | 2427Z247 | [1] | GLASS | |
| 13. | R27T0006D36 | [2] | RUBBER | KOB |
| 14. | R27T0006D41 | [2] | CHANNEL, RUBBER | CHANNEL, RUBBER |
| 15. | R27T0053D3 | [1] | CHANNEL, RUBBER | CHANNEL, RUBBER |
| 16. | R27T0006D42 | [1] | CHANNEL, RUBBER | CHANNEL, RUBBER |
| 18. | R27T0006D38 | [1] | CHANNEL, RUBBER | CHANNEL, RUBBER |
| 20. | 2432T912 | [4] | CLAMP | |
| 21. | R16T0419 | [4] | CLAMP | |
| 22. | R16T0420 | [2] | STOPPER | |
| 23. | ZS11C08020 | [18] | SCREW,Hex, M8 x 20mm, Cl 4.8 | KOBCAPTIVE WASHER SCREW CAPSCREW -- M08x1.25x20mm Superseded by part number: ZS18C08020 |
| 24. | ZW22X08000 | [23] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 25. | ZS31C06016 | [24] | SCREW,Phillips Drive, Pan HD, M6 x 16mm | KOBM06x1.0x16mm |
| 26. | ZN11C06005 | [36] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 27. | ZW22X06000 | [36] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 26. | ZN11C08007 | [9] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 29. | 2418T4549 | [1] | PLATE | |
| 30. | 2416Z176D5 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 31. | 2416Z176D6 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 32. | ZS41C06016 | [8] | SCREW,M6 x 16mm | KOBM06x1.0x16mm |
| 33. | 2416T4191 | [4] | SUPPORT | |
| 34. | 2427P1190D1 | [1] | LATCH | |
| 35. | 2420T2540 | [12] | CAPSCREW | |
| 36. | 2418T3991 | [4] | PLATE | KOB |
| 37. | 2416Z178 | [2] | RUBBER | RUBBER |
| 38. | ZN11C05004 | [8] | NUT M05x0.8mm | NUT M05x0.8mm |
| 39. | B90N0035F1 | [1] | CATCH ASSY,DOOR, CONSISTS OF REF 39-1 TO 39-7 | |
| 39-1. | B16P0146 | [1] | BRACKET | BRACKET |
| 39-2. | B16T0242 | [1] | PLATE | |
| 39-3. | B16T0243 | [1] | PLATE | |
| 39-4. | B17P0004 | [1] | SPRING | KOB |
| 39-5. | B19P0043D54 | [1] | PIN | KOBPIN Superseded by part number: ZP45X10045 |
| 39-6. | ZP15K02018 | [1] | SPRING | KOB Superseded by part number: ZP15K02035 |
| 39-7. | ZW11X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 40. | 4016Z14 | [1] | CUSHION | KOB |
| 41. | 4018T181 | [2] | WASHER | WASHER |
| 42. | 4017T2 | [1] | SPRING | SPRING |
| 43. | ZS11C08075 | [1] | CAPSCREW -- M08x1.25x75mm | |
| 44. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 45. | ZN21C08010 | [1] | NUT | KOBM08x1.25mm |
| 46. | ZP15K02018 | [1] | SPRING | KOB Superseded by part number: ZP15K02035 |
| 47. | ZS31C06008 | [5] | MACHINE SCREW M06x1.0x08mm | MACHINE SCREW M06x1.0x08mm |
| 48. | 2416T4192 | [1] | BRACKET | |
| 49. | 2416Z177D4 | [1] | SEAT, RUBBER | |
| 50. | 2416T4190 | [2] | BLOCK | |
| 51. | 2406Z208 | [1] | GRIP | GRIP |
| 52. | ZS11C08050 | [2] | CAPSCREW -- M08x1.25x50mm | |
| 53. | ZN11C08005 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08005 |
| 54. | R25P0009D49 | [4] | BEARING | KOB |
| 55. | 2427N963 | [1] | HANDLE | HANDLE |
| 56. | 2416Z183D2 | [2] | SEAT, RUBBER | SEAT, RUBBER |
| 57. | 2416Z176D4 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 58. | 2416Z176D7 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 59. | 2406Z207 | [1] | GRIP | |
| 60. | ZR36X00800 | [5] | SNAP RING | KOB |
| 61. | 2427R159 | [2] | STAY | KOB |
| 62. | R27P0015 | [2] | LATCH | |
| 63. | ZS31C06012 | [4] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 64. | 2414T856 | [1] | COVER | |
| 68. | ZS31C05010 | [8] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 69. | ZW22X05000 | [8] | LOCK WASHER | KOBID 05 x OD 09.2 x Th 1.3mm |
| 70. | 2427P1190D2 | [1] | LATCH | |
| 71. | ZS11C08025 | [6] | CAPSCREW -- M08x1.25x25mm | |
| 72. | 2416Z186D2 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 73. | 2416Z187D2 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 74. | 2416Z188 | [1] | RUBBER, CUSION | |
| 75. | ZN11C12007 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
| 76. | R16T0421 | [1] | RUBBER | |
| 77. | ZS31C06035 | [1] | SCREW,Phillips Drive, Pan HD, M6 x 35mm | KOBM06x1.0x35mm |
| 78. | ZW11X06000 | [1] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 79. | ZN11C06004 | [2] | NUT M06x1.0mm | NUT M06x1.0mm |
| 80. | 2418T5369 | [1] | PLATE | |
| 81. | 2427X207F1 | [1] | CAB,INCLUDE REF 81-79 TO 81-80 | |
| 81-79. | 2427Z298 | [1] | INSULATOR | KOB |
| 81-80. | 2427Z299 | [1] | INSULATOR | INSULATOR |
