纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-044) - VALVE ASSY, SELECTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
710 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX30V00060F1 | [1] | CONTROL VALVE | KOBVALVE ASSY, SELECTOR Superseded by part number: PX30V00060F3 |
| . . | PX30V00060F2 | [1] | CONTROL VALVE | KOBVALVE ASSY, SELECTOR |
| 1. | PX30V01037P1 | [1] | HOUSING | KOBHOUSING |
| 2. | PX30V01036P1 | [1] | SPOOL | KOBSPOOL |
| 3. | PX30V01034P1 | [1] | COVER | KOBCOVER (F1 ONLY) Superseded by part number: PX30V01041P1 |
| 4. | PX30V01018P1 | [1] | COVER | KOBCOVER |
| 5. | PX30V01022P1 | [1] | SPACER | KOBSPACER |
| 6. | PX30V01035P1 | [1] | LEVER | KOBLEVER (F1 ONLY) Superseded by part number: PX30V01059P1 |
| 7. | YN30V01012P1 | [1] | SEAL | KOBDUST (F1 ONLY) |
| 8. | ZD12G05000 | [2] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOB |
| 9. | ZD11P02800 | [1] | O-RING | KOB |
| 10. | PX30V01020P1 | [1] | BOLT | KOBBOLT (F1 ONLY) |
| 12. | ZS23C06020 | [2] | SCREW,Hex Socket Head, M6 x 20mm | KOBCAP Superseded by part number: ZS28C06020 |
| 13. | ZW16P06000 | [1] | WASHER | KOB(F1 ONLY) |
| 14. | PX30V01029P1 | [5] | PLUG | KOBPLUG |
| 15. | YN30V01027P1 | [1] | PLUG | KOB |
| 16. | YN30V01015P1 | [1] | BALL | KOB |
| 17. | YN30V01028P1 | [1] | SPRING | KOB |
| 18. | YN22T00264P1 | [1] | NAME PLATE | |
| 19. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 20. | ZS28C06016 | [15] | SCREW,Hex Socket Head, M6 x 16mm | KOBCAP (F1 ONLY) |
| 21. | PX30V01032P1 | [1] | SPACER | KOBSPACER (F1 ONLY) |
| 22. | ZS28C06025 | [1] | SCREW,Hex Socket Head, M6 x 25mm | KOBCAP (F1 ONLY) |
| 23. | PX30V01038P1 | [1] | COVER | KOBCOVER (F2 ONLY) |
| 24. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBCAPSCREW (F2 ONLY) |
| . . | PX30V00046R100 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF. 8(1), 9(1), 23(1), 24(1) (F1 ONLY) |
| . . | PX30V00060R200 | [1] | REPAIR KIT | KOBREPAIR KIT (F2 ONLY) |
