纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-045) - JOINT ASSY, SWIVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
567 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW55V00015F1 | [1] | JOINT ASSY. | KOBSWIVEL Superseded by part number: PW55V00015F2 |
| . . | PW55V00015F2 | [1] | JOINT ASSY. | KOBSWIVEL |
| 1. | PW55V00015S001 | [1] | SHAFT | KOB |
| 2. | PW55V00015S002 | [1] | ROTOR | KOB |
| 3. | PW55V00001S003 | [1] | FLANGE | KOB |
| 4. | PW55V00001S004 | [1] | SPACER | KOB |
| 5. | PW55V00001S005 | [1] | PIN | KOB |
| 6. | PW55V00015S006 | [7] | SEAL | KOB(F1 ONLY) |
| 7. | ZD12P08000 | [1] | O-RING | KOB |
| 8. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOB |
| 9. | ZD75P08000 | [1] | BACK-UP RING | KOB |
| 10. | PW55V00001S010 | [1] | SEAL | KOBDUST |
| 11. | PW55V00001S011 | [1] | SEAL | KOBDUST Superseded by part number: 2445R63 |
| 12. | PW55V00001S012 | [1] | SNAP RING | KOBRETAINING Superseded by part number: ZR26X07200 |
| 13. | ZS13C10030 | [4] | SCREW | KOBCAP Superseded by part number: ZS18C10030 |
| 14. | ZE82T04000 | [3] | PLUG | KOB |
| 15. | ZW22K10000 | [4] | WASHER | KOB |
| 16. | NSS | [1] | NOT SERVICED SEPARATELY | CONNAME PLATE |
| 17. | PW55V00015S017 | [3] | SEAL | KOB(F2 ONLY) |
