纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-002) - GEAR HOUSING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
377 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV72924001500 | [1] | TRANSMISSION HOUSING | KOBHOUSING ASSY, GEAR |
| 4. | VV23876030000 | [1] | PLUG | KOBPLUG PT3/8, SCREW |
| 5. | VV23876040000 | [1] | PLUG | KOBPLUG PT 1/2 |
| 6. | VV12979501800 | [1] | OIL SEAL | KOBSEAL, OIL |
| 7. | VV11980232100 | [1] | COVER ASSY | KOBCOVER ASSY, PUMP |
| 8. | VV11980232070 | [1] | COVER | KOBCOVER, LUB. OIL PUMP |
| 9. | VV12990032130 | [1] | VALVE | KOBVALVE, RELIEF |
| 10. | VV12941832320 | [1] | SPRING | KOBSPRING |
| 11. | VV12900132330 | [1] | PLUG | KOBPLUG |
| 12. | VV11980201520 | [1] | CASE | KOBFRANGE, GEAR CASE |
| 13. | VV11980201560 | [3] | STUD | KOBSTUD, M8 X 25 |
| 14. | VV12416001751 | [1] | CAP | KOBCOVER, FILLER |
| 15. | VV12424001871 | [1] | COVER | KOBHydraulic Oil Pump |
| 16. | VV12979501950 | [2] | PIPE | KOBPIPE, KNOCK L=18 |
| 17. | VV11960932040 | [4] | O-RING | KOBO-RING P16 |
| 18. | VV11980232111 | [1] | ROTOR | KOBROTOR, INNER |
| 19. | VV11980232120 | [1] | ROTOR | KOBROTOR, OUTER |
| 20. | VV11980232130 | [7] | SCREW | KOBSCREW, M6 X 16 |
| 21. | VV12185051960 | [1] | O-RING | KOBO-RING, F.I. PUMP |
| 22. | VV12900191841 | [3] | BOLT | KOBBOLT, M8 X 85 |
| 23. | VV24311000320 | [1] | O-RING | KOBO-RING 1A P-32.0 Superseded by part number: ZD11P03200 |
| 24. | VV26106080162 | [4] | BOLT,M8 x 16mm | KOBBOLT, M8 X 16 PLATED |
| 26. | VV26106080552 | [12] | BOLT,M8 x 55mm | KOBBOLT, M8 X 55 PLATED |
| 27. | VV12102301550 | [1] | COVER | KOBCOVER, BLIND |
| 28. | VV24341000240 | [1] | O-RING | KOBO-RING, 1A S-24.0 |
| 29. | VV26106060162 | [2] | BOLT,M6 x 16mm | KOBBOLT, M6 X 16 PLATED |
| 30. | VV97777001212 | [1] | GASKET | KOBGASKET, LIQUID (OPTIONAL) Superseded by part number: VV9777701207F |
| 31. | VV12961277260 | [3] | NUT | KOBNUT, GENERATOR |
