纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-004) - CYLINDER HEAD & BONNET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
548 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV12990007900 | [1] | GRAIN LIFTER | KOBLIFTER, ENGINE |
| 2. | VV26106080142 | [2] | BOLT,M8 x 14mm | KOBBOLT, M8 X 14 PLATED |
| 3. | VV12900411241 | [1] | SHAFT ASSY. | KOBSHAFT ASSY, ROCKER |
| 4. | VV12900411251 | [1] | SHAFT | KOBSHAFT, ROCKER ARM |
| 6. | VV11980211260 | [2] | SUPPORT | KOBSUPPORT, ROCKER ARM |
| 7. | VV11980211270 | [2] | SUPPORT | KOBSUPPORT, ROCKER ARM |
| 8. | VV11980211280 | [3] | STUD | KOBSTUD Superseded by part number: VV26226080182 |
| 9. | VV12915011280 | [3] | SPRING | KOBSPRING |
| 10. | VV12900411650 | [6] | ARM ASSY. | KOBARM ASSY, ROCKER |
| 11. | VV12915011230 | [6] | SCREW | KOBSCREW, VALVE |
| 13. | VV12915011750 | [6] | NUT | KOBNUT, M8 X P1.0 |
| 14. | VV12915011370 | [6] | CAP | KOBCAP, VALVE |
| 15. | VV12900411700 | [1] | CYLINDER HEAD | KOBHEAD ASSY, CYLINDER |
| 19. | VV12013011860 | [3] | VALVE GUIDE | KOBGUIDE, VALVE |
| 21. | VV12915011810 | [3] | VALVE GUIDE | KOBGUIDE, VALVE |
| 23. | VV27241400000 | [2] | PLUG | KOBPLUG 40 |
| 24. | VV12900411100 | [3] | VALVE | KOBVALVE, INTAKE Superseded by part number: VV12900411130 |
| 25. | VV12910011110 | [3] | STD EXHAUST VALVE | KOBSTD ENGINE EXHAUST VALVE VALVE, EXHAUST Superseded by part number: VV12910011112 |
| 26. | VV12979511120 | [6] | VALVE SPRING | KOBSPRING, VALVE |
| 27. | VV12979511180 | [6] | SPRING | KOBRETAINER, SPRING |
| 28. | VV12140011340 | [3] | SEAL | KOBSEAL, VALVE STEM |
| 29. | VV12446011340 | [3] | SEAL | KOBSEAL, VALVE STEM |
| 31. | VV11980211870 | [3] | PROTECTOR | KOBPROTECTOR, NOZZLE |
| 32. | VV11962511880 | [3] | SEAT | KOBSEAT, NOZZLE |
| 33. | VV12900411900 | [3] | RETAINER | KOBRETAINER, NOZZLE |
| 34. | VV12027054410 | [3] | WASHER | KOBWASHER |
| 35. | VV22351060012 | [2] | SPRING,6 x 12mm | KOBSPRING PIN 6 X 12 |
| 36. | VV26106080252 | [2] | BOLT,M8 x 25mm | KOBBOLT M8 X 25 PLATED |
| 37. | VV26106080352 | [3] | BOLT,M8 x 35mm | KOBBOLT M8 X 35 PLATED |
| 38. | VV26106080502 | [6] | BOLT,M8 x 50mm | KOBBOLT M8 X 50 PLATED |
| 39. | VV12416001751 | [1] | CAP | KOBCOVER, FILLER |
| 40. | VV12900411350 | [1] | COVER | KOBBONNET ASSY, HEAD |
| 41. | VV12900403010 | [1] | PLATE ASSY. | KOBPLATE, BAFFLE |
| 42. | VV12915003070 | [1] | BAFFLE | KOBBAFFLE, BREATHER |
| 43. | VV11980203110 | [1] | PLATE | KOBPLATE, DIAPHRAGM |
| 44. | VV11980203120 | [1] | COVER ASSY | KOBCOVER, DIAPHRAGM |
| 45. | VV11980203130 | [1] | DIAPHRAGM | KOBDIAPHRAGM |
| 46. | VV11980203140 | [1] | SPRING | KOBSPRING, DIAPHRAGM Superseded by part number: VV11980203141 |
| 49. | VV12900411310 | [1] | GASKET | KOBGASKET, BONNET |
| 50. | VV22857500100 | [4] | SCREW,M5 x 10mm | KOBSCREW 5 X 10, TAPPING |
| 52. | VV12416011360 | [3] | KNOB | KOBKNOB |
| 53. | VV24311000120 | [3] | O-RING | KOBO-RING, 1A P 12.0 Superseded by part number: ZD11P01200 |
| 54. | VV24311000320 | [1] | O-RING | KOBO-RING, 1A P-32.0 Superseded by part number: ZD11P03200 |
