纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-008) - CRANKSHAFT & PISTON New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV12900421001 | [1] | CRANKSHAFT | KOBCRANKSHAFT ASSY Superseded by part number: VV12900421002 |
| 2. | VV12910001580 | [1] | PIN,M8 x 16mm | KOBPARALLEL PIN 8 X 16 |
| 5. | VV11980221201 | [1] | GEAR | KOBGEAR, CRANKSHAFT |
| 6. | VV22512070140 | [1] | KEY,M7 x 14mm | KOBKEY, 7 X 14 |
| 8. | VV22351030010 | [1] | PIN | KOBSPRING PIN 3 X 10 |
| 9. | VV12900421650 | [1] | PULLEY | KOBV-PULLEY, CRANKSHAFT |
| 10. | VV12979521661 | [1] | WASHER | KOBWASHER |
| 11. | VV12185021680 | [1] | BOLT | KOBBOLT, V-PULLEY |
| 12. | VV12111121501 | [6] | BOLT | KOBBOLT, FLYWHEEL |
| 13. | VV12912821590 | [1] | FLYWHEEL | KOBFLYWHEEL W/RING GEAR |
| 15. | VV11986521600 | [1] | GEAR | KOBGEAR, RING |
| 16. | VV12900522080 | [3] | PISTON ASSY | KOBPISTON ASSY |
| 18. | VV12900522500 | [3] | PISTON RING SET | KOBRING SET, PISTON |
| 22. | VV12920222300 | [3] | PISTON PIN | KOBPIN, PIST0N (D26, L70) |
| 23. | VV22252000260 | [6] | CIRCLIP | KOBCIRCLIP 26 |
| 24. | VV72940223100 | [3] | ROD | KOBROD ASSY, CONNECTING |
| 28. | VV12910023910 | [3] | BUSHING | KOBBUSH, PISTON PIN |
| 29. | VV12155023200 | [6] | BOLT | KOBBOLT, CONNECTING ROD |
| 30. | VV12915023600 | [3] | CRANKSHAFT BEARING | KOBBEARING, CRANKPIN |
| 32. | VV12915023610 | [3] | PIN | KOBMETAL PIN US=O. 25 |
| 34. | VV12900522900 | [3] | PISTON | KOBPISTON W/RING 0S= 25 |
| 36. | VV12900522950 | [3] | RING | KOBRING SET. O.S=O. 25 |
