纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-010) - COOLING WATER SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV12900442000 | [1] | WATER PUMP | KOBPUMP ASSY, WATER Superseded by part number: VV12900442001 |
| 3. | VV12910042051 | [1] | GASKET | KOBGASKET, (NON-ASB.) |
| 4. | VV12910042121 | [1] | PLATE | KOBPLATE |
| 8. | VV12185042410 | [3] | SCREW | KOBSCREW |
| 10. | VV11980249112 | [2] | PIPE | KOBPIPE, COOLING WATER Superseded by part number: VV11980249113 |
| 11. | VV23876010000 | [1] | PLUG | KOBPLUG PT1/8, SCREW |
| 12. | VV23876020000 | [1] | PLUG | KOBPLUG 1/4 |
| 13. | VV23876030000 | [2] | PLUG | KOBPLUG PT3/8, SCREW |
| 14. | VV12948642021 | [1] | GASKET | KOBGASKET |
| 15. | VV12900442040 | [1] | JOINT | KOBJOINT |
| 16. | VV12948642140 | [1] | O-RING | KOBO-RING, CW-P |
| 17. | VV12439549840 | [1] | GASKET | KOBGASKET, THERMO. CASE |
| 18. | VV26106080162 | [3] | BOLT,M8 x 16mm | KOBBOLT M8 X 16 PLATED |
| 19. | VV26106080602 | [3] | BOLT,M8 x 60mm | KOBBOLT M8 X 60 PLATED |
| 20. | VV12915542350 | [1] | PULLEY | KOBV-PULLEY, C.W. PUMP |
| 21. | VV12961242330 | [1] | V-BELT | KOBV-BELT |
| 22. | VV17134044740 | [1] | FAN | KOBFAN, COOLING |
| 23. | VV17135344760 | [1] | SPACER | KOBSPACER |
| 24. | VV26106060402 | [4] | BOLT,M6 x 40mm | KOBBOLT M6 X 40 PLATED |
| 25. | VV12915549801 | [1] | THERMOSTAT | KOBTHERMOSTAT (71) |
| 26. | VV12915049811 | [1] | GASKET | KOBGASKET, (NON-ASB.) |
| 27. | VV12935049530 | [1] | COVER | KOBCOVER, THERMOSTAT |
| 28. | VV12979549551 | [1] | GASKET | KOBGASKET, (NON-ASB.) |
| 29. | VV26106080222 | [2] | BOLT,M8 x 22mm | KOBBOLT M8 X 22 PLATED |
| 30. | VV23414080000 | [1] | SEAL | KOBGASKET 8, ROUND |
| 31. | VV12145042450 | [1] | PLUG,M16 | KOBPLUG M16 |
| 32. | VV12125044901 | [1] | THERMOSTATIC SWITCH,On - 110° C, 230° F | KOBSWITCH, THERMO (110°C) |
| 33. | VV12446544950 | [1] | GASKET | KOBGASKET 16 |
| 34. | VV12915049360 | [1] | PACKING | KOBGASKET 10 |
| 35. | VV12900449610 | [1] | PIPE ASSY. | KOBPIPE ASSY, A MP2 |
| 36. | VV12900449711 | [1] | PIPE ASSY. | KOBPIPE ASSY, A MP2 |
| 37. | VV11980249730 | [1] | CLAMP | KOBCLAMP, CW-T |
| 38. | VV12472259050 | [2] | CLAMP | KOBCLAMP 9 |
| 39. | VV12900449620 | [1] | PIPE ASSY. | KOBPIPE ASSY, B MP2 |
| 40. | VV12900449721 | [1] | PIPE | KOBPIPE, WATER B MP2 |
| 42. | VV26106080122 | [1] | BOLT,M8 x 12mm | KOBBOLT, M8 X 12 PLATED |
| 43. | VV17105649120 | [1] | PLUG | KOBPLUG, DRAIN |
| 44. | VV26106080452 | [1] | BOLT,M8 x 45mm | KOBBOLT, M8 X 45 PLATED |
| 46. | VV12146844510 | [1] | TANK | KOBSUB-TANK ASSY Superseded by part number: VY12146844520 |
| 48. | VV12145044531 | [1] | CAP | KOBCAP Superseded by part number: VY12145044531 |
| 49. | VV12146844540 | [1] | PLUG | KOBPLUG, SUB-TANK Superseded by part number: VY12146844540 |
| 50. | VV12445044560 | [1] | CLAMP | KOBCLAMP Superseded by part number: VY12445044560 |
| 51. | VV12147044581 | [1] | GASKET | KOBGASKET Superseded by part number: VY12147044581 |
| 52. | VV23065070130 | [1] | PIPE | KOBPIPE 7 X 130 Superseded by part number: VV23061070230 |
