纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-011) - FUEL INJECTION PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
499 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV72924551310 | [1] | FUEL INJECTION PUMP | KOBPUMP ASSY, F. INJECT |
| . . | VV11923377932 | [1] | SOLENOID | KOBStop (Fuel Shut-Off) -- Not Shown |
| 249. | VV11980251250 | [1] | BRACKET | KOBBRACKET, PUMP |
| 250. | VV26106080162 | [1] | BOLT,M8 x 16mm | KOBBOLT, M8 X 16 PLATED |
| 251. | VV26106080202 | [1] | BOLT,M8 x 20mm | KOBBOLT, M8 X 20 PLATED |
| 253. | VV11928566650 | [1] | CAP | KOBCAP, HIGH-IDLE |
| 254. | VV12920961940 | [1] | CASE | KOBCASE ASSY |
| 256. | VV12920961960 | [1] | CASE | KOBCASE |
| 257. | VV24311000150 | [1] | O-RING | KOBO-RING, 1A P-15.0 Superseded by part number: ZD11P01500 |
