纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-013) - FUEL LINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
538 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV12900455610 | [1] | BRACKET | KOBBRACKET, FILTER Superseded by part number: VV12900455612 |
| 2. | VV11980255800 | [1] | FUEL FILTER | KOBFILTER, FUEL Superseded by part number: 84557062 |
| 3. | VV26106080302 | [2] | BOLT,M8 x 30mm | KOBBOLT, M8 X 30 PLATED |
| 4. | VV12921059100 | [1] | PIPE ASSY. | KOBPIPE ASSY, FUEL |
| 5. | VV12476659050 | [2] | CLAMP | KOBCLAMP 12 Superseded by part number: VY12476659050 |
| 6. | VV10502559580 | [1] | PIPE | KOBPIPE, FUEL OIL |
| 7. | VV12921059230 | [1] | PIPE ASSY. | KOBPIPE ASSY, FUEL OIL |
| 9. | VV12955559511 | [1] | PIPE | KOBPIPE, FUEL |
| 10. | VV12961252100 | [1] | FUEL PUMP,12V, 1.5A | KOBFUEL PUMP |
| 11. | VV11980255700 | [1] | SEPARATOR | KOBSEPARATOR ASSY |
| 12. | VV11980255710 | [1] | FILTER STRAINER | KOBELEMENT Superseded by part number: 47530395 |
| 13. | VV12910055690 | [1] | RING | KOBRING, RETAINING |
| 14. | VV24321000650 | [1] | O-RING | KOBO-RING 1A G-65.0 Superseded by part number: ZD11G06500 |
| 15. | VV24311000160 | [1] | O-RING | KOBO-RING 1A P-16.0 Superseded by part number: ZD11P01600 |
