纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (08-014) - STARTING MOTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VV26116120252 | [2] | BOLT | KOBBOLT, M12 X 25 PLATED Superseded by part number: VY26116120252 |
| 2. | VV12924277010 | [1] | STARTER MOTOR | KOBSTARTER |
| 3. | VV12969877020 | [1] | SWITCH | KOBMAGNETIC SWITCH ASSY |
| 4. | VV12924277100 | [1] | ARMATURE | KOBARMATURE ASSY |
| 5. | VV12924277110 | [1] | VALVE | KOBYOKE ASSY |
| 6. | VV12924277120 | [1] | BRUSH HOLDER | KOBBRUSH HOLDER ASSY |
| 7. | VV12924277130 | [2] | BRUSH | KOBBRUSH (-) |
| 8. | VV12924277140 | [1] | BRUSH SET | KOBBRUSH (+) SET |
| 9. | VV12924277150 | [4] | SPRING | KOBBRUSH SPRING |
| 10. | VV12924277160 | [1] | COVER | KOBREAR COVER ASSY |
| 11. | VV12924277170 | [1] | COVER | KOBREAR COVER METAL |
| 12. | VV11840077170 | [3] | GEAR | KOBPLANET GEAR Superseded by part number: VV12969877240 |
| 13. | VV12924277180 | [1] | BRACKET | KOBCENTER BRACKET (P) |
| 14. | VV12969877190 | [1] | BRACKET | KOBBRACKET |
| 15. | VV12969877200 | [1] | GEAR | KOBINTERNAL GEAR |
| 16. | VV12924277210 | [1] | BRACKET | KOBCENTER BRACKET (A) |
| 17. | VV12969877220 | [1] | PINION | KOBPINION ASSY |
| 18. | VV12969877230 | [1] | SHAFT | KOBSHAFT (PINION) |
| 19. | VV12969877250 | [1] | WASHER | KOBWASHER SET |
| 20. | VV12924277260 | [1] | CASE | KOBGEAR CASE ASSY |
| 21. | VVX2114535200 | [1] | SLEEVE | KOBMETAL, STARTER |
| 22. | VV12924277270 | [1] | LEVER | KOBSHIFT LEVER SET |
| 23. | VV12924277280 | [1] | COVER | KOBDUST COVER KIT |
| 24. | VV12419577770 | [2] | BOLT | KOBBOLT, THROUGH Superseded by part number: VV11926077260 |
