纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-037) - CYLINDER ASSY, OFFSET (OFFSET BOOM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
206 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YR01V00019F1 | [1] | CYLINDER | KOBOFFSET |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER |
| 3. | YR01V00019S003 | [1] | CYLINDER HEAD | KOB |
| 4. | YR01V00019S004 | [1] | BUSHING | KOB |
| 5. | 2438U717S6 | [1] | RING | KOBSNAP |
| 6. | YR01V00019S006 | [1] | RING | KOBBUFFER |
| 7. | 2438U717S13 | [1] | SNAP RING | KOBU |
| 8. | LE01V00019S009 | [1] | RING | KOBWIPER Superseded by part number: 2438U717S12 |
| 9. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOB |
| 10. | PY01V00030S008 | [1] | BACK-UP RING | KOB |
| 11. | ZD11G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOB |
| 12. | YR01V00019S012 | [1] | PISTON | KOB |
| 13. | 2438U827S20 | [1] | SEALING RING | KOBSEALRING |
| 14. | PY01V00030S017 | [2] | RING | KOBSLIDE |
| 15. | 2438U986S18 | [1] | SET SCREW | KOBSET |
| 16. | 2436U281S37 | [1] | BALL | KOB |
| 17. | 2438U716S2 | [2] | BUSHING | KOB |
| 18. | 2438U716S25 | [4] | SEAL | KOBWIPER |
| 19. | YR01V00014S021 | [1] | BAND | KOBASSY |
| 20. | LE01V00002S031 | [1] | BALL | KOB |
| 21. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 22. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | YR01V00019R100 | [1] | SEAL | KOBROD SIDE CONSISTS OF REF. 6 (1), 7 (1), 8 (1), 9 (1), 10 (1), 11 (1) |
| . . | YR01V00019R200 | [1] | SEAL | KOBPISTON SIDE CONSISTS OF REF. 13 (1), 14 (2) |
| . . | YR01V00019R300 | [1] | SEAL | KOBALL (ROD + PISTON) CONSISTS OF REF. 6 (1), 7 (1), 8 (1), 9 (1), 10 (1), 11 (1), 13 (1), 14 (2) |
| . . | YR01V00019R400 | [1] | TUBE | KOBCONSISTS OF REF. 1 (1), 17 (1) |
| . . | YR01V00019R500 | [1] | ROD | KOBCONSISTS OF REF. 2 (1), 17 (1) |
