纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-040) - CYLINDER ASSY, BOOM (2-PIECE BOOM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
262 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT01V00004F1 | [1] | CYLINDER ASSY. | KOBBOOM Superseded by part number: YT01V00004F2 |
| . . | YT01V00004F2 | [1] | CYLINDER ASSY. | KOBBOOM |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER, (F1 ONLY) |
| 3. | YR01V00006S003 | [1] | CYLINDER HEAD | KOB |
| 4. | YR01V00001S004 | [1] | BUSHING | KOB Superseded by part number: 2438U1094S4 |
| 5. | 2438U721S7 | [1] | SNAP RING | KOBRETAINING |
| 6. | 2438U721S20 | [1] | RING | KOBBUFFER |
| 7. | 2438U721S16 | [1] | RING | KOBU |
| 8. | 2438U721S17 | [1] | BACK-UP RING | KOBBACK UP |
| 9. | YT01V00001S009 | [1] | RING | KOBWIPER |
| 10. | ZD12G10500 | [1] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOB |
| 11. | 2438U1949S12 | [3] | RING | KOBBACK UP |
| 12. | ZD11G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOB |
| 13. | ZD12G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOB |
| 14. | YR01V00001S014 | [1] | BEARING | KOBCUSHION |
| 15. | YT01V00001S015 | [1] | SEAL | KOBCUSHION |
| 16. | YT01V00001S016 | [1] | PISTON | KOB |
| 17. | 2438U716S23 | [1] | SEAL | KOBSEALRING SEAL |
| 18. | 2438U716S24 | [2] | RING | KOBSLIDE |
| 19. | 2438U1094S21 | [1] | SHIM | KOB |
| 20. | YT01V00001S020 | [1] | NUT | KOB |
| 21. | 2438U999S21 | [1] | SET SCREW | KOBSET |
| 22. | 2436U330S16 | [1] | BALL | KOB |
| 23. | YT01V01008P1 | [1] | BUSHING | KOB |
| 24. | 2438U1946S25 | [2] | RING | KOBWIPER |
| 25. | YT01V01007P1 | [1] | BUSHING | KOB |
| 26. | LP01V00007S026 | [2] | RING | KOBWIPER |
| 27. | YT01V00001S027 | [2] | BAND | KOBASSY |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | YT01V00001R100 | [1] | REPAIR KIT | KOBROD SIDE CONSISTS OF REF. 6 (1), 7 (1), 8 (1), 9 (1), 10 (1), 11 (1), 12 (1), 13 (1) |
| . . | 2438U716R140 | [1] | SEAL KIT | KOBPISTON SIDE CONSISTS OF REF. 17 (1), 18 (2) Superseded by part number: 2438U716R140P |
| . . | YT01V00001R300 | [1] | REPAIR KIT | KOBALL (ROD + PISTON) CONSISTS OF REF. 6 (1), 7 (1), 8 (1), 9 (1), 10 (1), 11 (1), 12 (1), 13 (1), 17 (1), 18 (2) |
| . . | YT01V00004R400 | [1] | TUBE | KOBREPAIR KIT, CONSISTS OF REF. 1 (1), 23 (1), (F1 ONLY) |
| . . | YT01V00004R500 | [1] | ROD | KOBREPAIR KIT, CONSISTS OF REF. 2 (1), 25 (1) |
| . . | YT01V00004R600 | [1] | TUBE | KOBREPAIR KIT, CONSISTS OF REF. 23 (1), 30 (1), (F2 ONLY) |
