纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (04-001) - TOOLS & ACCESSORIES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
960 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT01T00002FE | [1] | TOOL & ACCESSORY | |
| 1. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER |
| 2. | 2406R527 | [1] | HANDLE | KOBRATCHET |
| 3. | 2406Z623D3 | [1] | BAR | KOBEXTENSION |
| 4. | ZT22A05000 | [1] | KEY | KOBSCREW |
| 5. | ZT22A08000 | [1] | KEY | KOBSCREW |
| 8. | 2421R397 | [1] | HAMMER | KOB |
| 9. | LE01T01006P1 | [1] | ADJUSTING WRENCH | KOBBOX |
| 10. | YW01T01014P1 | [1] | ADJUSTING WRENCH | KOB |
| 11. | 2421R140 | [1] | NOZZLE | KOB |
| 12. | 2421Z296 | [1] | ADJUSTING WRENCH | KOBSET SPANNER |
| 15. | 2408R587D1 | [1] | SOCKET | KOB |
| 16. | 2408R587D2 | [1] | SOCKET | KOB |
| 17. | 2408R587D3 | [1] | SOCKET | KOB |
| 18. | 2408R587D4 | [1] | SOCKET | KOB |
| 19. | 2408R587D6 | [1] | SOCKET | KOBSOCKET |
| 20. | 2421R392 | [1] | TOOL | KOBPLIER |
| 21. | 2421R398 | [1] | ADJUSTING WRENCH | KOBPIPE |
| 22. | PW01T01003P1 | [1] | CASE | KOB |
| 25. | B16T0442D41 | [4] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOB |
| 26. | B16T0442D43 | [4] | SHIM,0.9mm Thk | KOB |
| 27. | B16T0442D81 | [2] | SHIM,120mm OD x 77mm ID x 0.9mm Thk | KOB(0.9) |
| 28. | B16T0442D93 | [2] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOB(0.9) |
| 29. | YR02B01266D1 | [2] | SHIM | KOB(0.9) |
| 34. | YN20T01320P1 | [1] | LABEL | KOBWARNING: DO NOT OPERATE |
