纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (02-001) - LOW GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
511 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT15V00008F1 | [2] | MOTOR | KOBASSY, HYD |
| A1. | YT02F00046P1 | [1] | FRAME | KOBFRAME, LOW |
| A1-4. | YT07F01034P1 | [2] | SUPPORT | KOB |
| A1-5. | YY41C00005P1 | [4] | STEP | KOB |
| . . | YT01F00005F1 | [1] | LOW GROUP (FOR IRON) | |
| B1. | YT01F01014P1 | [2] | COVER | KOB |
| B2. | YT01F01005P1 | [2] | GUIDE | KOB(L.H.) |
| B3. | YT01F01006P1 | [2] | GUIDE | KOB(R.H.) |
| B4. | 2422T556 | [1] | PLATE | KOB |
| B5. | 2418T12274 | [1] | PACKING | KOB |
| B6. | ZS13C14035 | [12] | CAPSCREW | KOBSCREW CAP Superseded by part number: ZS18C14035 |
| B7. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBCAP YT04-07175, Serial Range: -YT04-08162 |
| B8. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOBCAP |
| B9. | 2418T17441D1 | [12] | WASHER | KOB |
| B10. | ZW16X12000 | [8] | WASHER | KOB, Serial Range: YT04-07175-YT04-08162 |
| B11. | ZW26X12000 | [8] | WASHER | KOB, Serial Range: YT04-07175-YT04-08162 |
| B12. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B13. | YT63D00005P1 | [2] | GUIDE | KOBTRACK |
| B14. | ZS18C16030 | [8] | SCREW,Hex, M16 x 30mm | KOBCAP |
| B15. | ZW16H16000 | [8] | WASHER | KOB |
| B16. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBSEMS, Start Serial: YT04-08163 |
| . . | YT01F00006F1 | [1] | LOW GROUP (FOR RUBBER) | |
| C9. | YT01F01008P1 | [16] | CAP | KOB |
| C10. | YT01F01007P1 | [12] | CAP | KOB |
| . . | LE19H00001F1 | [1] | JOINT INSTAL, SWIVEL | |
| D1. | 24100J12125F2 | [1] | UNIVERSAL JOINT | KOBASSY, SWIVEL |
| D2. | ZS23C08020 | [3] | SCREW,Hex Socket Head, M8 x 20mm | KOBCAP |
| D3. | ZS18C16090 | [1] | SCREW,Hex, M16 x 90mm | KOBCAP |
| D4. | ZW22K08000 | [3] | LOCK WASHER | KOB |
| D5. | ZN18C16013 | [1] | NUT | KOB |
| . . | LE53D00001F1 | [1] | MOTOR INSTAL, PROPEL | |
| E1. | 2404N267 | [2] | SPROCKET | KOB |
| E3. | LE53D01001P1 | [24] | SCREW | KOBCAP |
