纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-011) - PUMP ASSY, FUEL, P/N YT22P00003F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
335 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22P00003F1 | [1] | PUMP ASSY, FUEL | |
| 1. | YF22P00003F3 | [1] | PUMP | KOBASSY, FUEL |
| 1-2. | 2444Z1233D7 | [1] | ELEC CONNECTOR | KOB |
| 1-3. | 2446Z143 | [1] | STRAINER ASSY. | KOB |
| 1-4. | YF22P01004D1 | [1] | HOSE | KOB |
| 1-5. | ZC15X02600 | [2] | CLAMP | KOB |
| 1-7. | YF22P00002F3 | [1] | PUMP | KOBASSY, FUEL, SEE FIG. 01-012 |
| 2. | YT22P01007P2 | [1] | BOXED PANEL | KOB |
| 3. | YT22P01004P1 | [1] | ELBOW | KOB |
| 4. | 2427Z1594D031 | [1] | TRIM PANEL | KOB |
| 5. | YJ21C01146D3 | [2] | INSULATING PANEL | KOBTRIM |
| 6. | YR21C01159P1 | [8] | BOLT | KOBSEMS |
| 8. | ZC46X25011 | [1] | CLIP | KOB |
| 9. | ZC16X02800 | [2] | CLIP | KOB |
| 10. | ZC16X01800 | [2] | CLIP | KOB |
| 11. | 2444R2492D035 | [1] | HOSE | KOB |
| 12. | YT22P01003P1 | [1] | ADAPTER | KOB |
| 13. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 14. | ZW16K10000 | [1] | WASHER | KOB |
| 15. | ZM32C12025 | [1] | BOLT | KOBSEMS |
| 16. | ZM11C06020 | [2] | SCREW | KOBSEMS |
| 17. | ZW16X06000 | [2] | WASHER | KOB Superseded by part number: 86588450 |
| 18. | YT22P01008P1 | [1] | BRACKET | KOB |
| 19. | YX14E01004P1 | [1] | GROMMET | KOB |
| 20. | PM22C01020D7 | [1] | STRIP | KOB |
| 21. | PM22C01020D9 | [1] | TRIM PANEL | KOB |
| 22. | YY22P01026P1 | [1] | RUBBER | KOB |
| 23. | YF22P01004D4 | [1] | FLEXIBLE HOSE | KOB |
| 24. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 25. | YR21C01161P1 | [2] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 26. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
