神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (08-005) - BUCKET ASSY, 2.0M³ Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
332 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P859F1 | [1] | BUCKET ASSY, 2.0M3, Serial Range: LU.0096--LU.0139 | |
| . . | 24100P859F2 | [1] | BUCKET ASSY, 2.0M3, Start Serial: LU.0140- | |
| 1. | 2412X270F1 | [1] | BUCKET, Serial Range: LU.0096--LU.0139 | |
| 1-29. | 2405T839 | [4] | BUSHING | KOB, Serial Range: LU.0096--LU.0139 |
| 2. | 2412U28F1 | [4] | POINT ASSY | |
| 2-1. | 2412U28S1 | [1] | PIN, LOCKING | PIN, LOCKING |
| 2-2. | 2412U28S2 | [1] | SHEAR BOLT RUBBER | SHEAR BOLT RUBBER |
| 2-3. | 2412U28S3 | [1] | POINT | POINT |
| 3. | 2412P238D1 | [1] | CUTTER | KOB |
| 4. | 2412P238D2 | [1] | CUTTER | KOB |
| 5. | ZS18C30085 | [10] | SCREW,Hex, M30 x 85mm | KOB |
| 6. | ZN18C30024 | [10] | NUT | KOBM30x2.0mm |
| 7. | 2412X508F1 | [1] | BUCKET, Start Serial: LU.0140- | |
| 7-28. | 2412U39 | [4] | ADAPTER | KOBBUSHING, Start Serial: LU.0140- |
