神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (08-008) - BUCKET ASSY, 1.4M³ FOR ARM 5.25M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N1357F1 | [1] | BUCKET ASSY, 1.4M3 | |
| . . | 2412X193F1 | [1] | BUCKET | |
| 1-24. | 2405T648 | [4] | BUSHING | KOB |
| 1-25. | 2445R138D8 | [8] | SEAL,90mm ID x 105mm OD x 4mm Thk | KOBDust -- ID 90 x OD 105 x Th 4mm |
| 2. | 2412P265F1 | [4] | TOOTH ASSY | |
| 2-1. | 2412P265S1 | [1] | TOOTH | TOOTH |
| 2-2. | B12K0014E2 | [1] | PIN, LOCKING | PIN, LOCKING |
| 2-3. | B12K0014E3 | [1] | SHEAR BOLT LOCK-PIN, RUBBER | SHEAR BOLT LOCK-PIN, RUBBER |
