纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-007[00]) - CYLINDER HEAD COVER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
967 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980305370 | [1] | COVER | KOBCyl. Hd. |
| 2. | VI0911801060 | [2] | NUT | KOBCover, Hd. |
| 3. | VI8944256852 | [1] | CAP | KOBOil Filler |
| 4. | VI8941236231 | [1] | GASKET | KOBOil Filler |
| 5. | VI0280506200 | [7] | BOLT | KOBHd. Cover |
| 6. | VI0280506450 | [3] | BOLT | KOBHd. Cover |
| 7. | VI0410106200 | [2] | STUD | KOBCover, Hd. |
| 8. | VI8980305381 | [1] | GASKET | KOBHd. To Cover |
