凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (07.03[01]) - EMERGENCY BRAKE SYSTEM, FRANCE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
639 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80150014
|
[1] |
FERRULE
|
ZED
10 MM Superseded by part number: 150014
|
| 2. |
86548975
|
[1] |
PIPE UNION NUT,M16 x 1.5
|
ZED
M10
|
| 3. |
80371539
|
[1] |
RIGID TUBE
|
ZED
D= 10 MM, L= 2 M Superseded by part number: 371539
|
| 4. |
80418284
|
[3] |
ELBOW
|
ZED
Superseded by part number: 418284
|
| 5. |
80734031
|
[2] |
HYD CONNECTOR
|
ZED
Superseded by part number: 734031
|
| 6. |
84078038
|
[1] |
VALVE,M16 x 1.5 x M16 x 1.5
|
ZED
|
| 7. |
80395019
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 395019
|
| 8. |
84018412
|
[1] |
ACCUMULATOR,0.5L
|
ZED
|
| 9. |
84078103
|
[1] |
SUPPORT
|
ZED
|
| 10. |
80140110
|
[1] |
WASHER
|
ZED
Superseded by part number: 140110
|
| 11. |
80308823
|
[1] |
NUT
|
ZED
M28 Superseded by part number: 308823
|
| 12. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 14. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 15. |
89839198
|
[1] |
CABLE
|
ZED
Superseded by part number: 9839198
|
| 16. |
80921153
|
[1] |
PLATE
|
ZED
Superseded by part number: 921153
|
| 17. |
80433101
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 433101
|
| 18. |
80300507
|
[1] |
SCREW
|
ZED
M6 x 30 Superseded by part number: 86977789
|
| 19. |
80353308
|
[1] |
NUT
|
ZED
M6 Superseded by part number: 353308
|
| 20. |
84320121
|
[1] |
DRAINCOCK/TAP SUPPLY,M16 x 1.5 x M16 x 1.5
|
ZED
|
| 21. |
80433008
|
[2] |
CLAMP
|
ZED
Superseded by part number: 433008
|
| 22. |
80368582
|
[2] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 23. |
84607248
|
[1] |
WIRE CLAMP
|
ZED
|
| 24. |
84078105
|
[1] |
RING
|
ZED
|
| 25. |
89507809
|
[1] |
CLAMP
|
ZED
Superseded by part number: 9507809
|
| 26. |
80120100
|
[1] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
