纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-013[01]) - ENGINE ELECTRICAL CONTROL PARTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
693 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8971822892 | [1] | GENERATOR | KOBAsm., See Figure 08-015-00 |
| 2. | VI0280558120 | [1] | BOLT | KOBGen. |
| 3. | VI8980488900 | [1] | BRACKET | KOBGen. |
| 4. | VI0911802080 | [1] | NUT | KOBGen. |
| 5. | VI0280508700 | [1] | BOLT | KOBGen. Brkt. |
| 6. | VI0280510450 | [1] | BOLT | KOBGen. Brkt. |
| 7. | VI8972091152 | [1] | SOLENOID | KOBAsm, Eng. Stop |
| 8. | VI9095714140 | [2] | GASKET | KOBPickup |
| 9. | VI8941268220 | [1] | SENSOR | KOBTacho Superseded by part number: VIG1466721020 |
