| 1. |
84607792
|
[1] |
AUGER
|
ZED
RH
|
| 2. |
84607791
|
[1] |
AUGER
|
ZED
LH
|
| 3. |
80140046
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 4. |
80120044
|
[4] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 5. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 6. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
84818903
|
[1] |
FRAME
|
ZED
(28) Superseded by part number: 86500688, 9832679, 84162041, 87535752, 100038, 370006, 84025509, 322357, 87663292, 120100, 84162039, 140015, 43158, 87335294
|
| 7. |
84818906
|
[1] |
FRAME
|
ZED
(28) Superseded by part number: 322357, 84025509, 87616401, 9832679, 87535752, 87335294, 86500688, 140015, 120100, 43158, 100038, 370006, 84162041, 84162039
|
| 8. |
84607767
|
[1] |
ANGLE
|
ZED
LH
|
| 8. |
84607768
|
[1] |
ANGLE
|
ZED
RH
|
| 9. |
86512446
|
[6] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 10. |
84607735
|
[2] |
ARM
|
ZED
|
| 11. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 12. |
84818450
|
[2] |
CARRIAGE BOLT,M12 x 85mm, Cl 8.8
|
ZED
|
| 13. |
84041968
|
[2] |
LOCKING PLATE
|
ZED
|
| 14. |
89706685
|
[6] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 15. |
84607772
|
[1] |
GUARD
|
ZED
|
| 16. |
84607781
|
[1] |
GUARD
|
ZED
, Serial Range: -C547 Superseded by part number: 84274384
|
| 16. |
84801614
|
[1] |
GUARD
|
ZED
, Start Serial: D548 Superseded by part number: 84274384
|
| 17. |
86511478
|
[1] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 18. |
84041969
|
[1] |
PLATE
|
ZED
|
| 19. |
80412607
|
[3] |
PIN
|
ZED
Superseded by part number: 412607
|
| 20. |
80130004
|
[3] |
COTTER PIN
|
ZED
Superseded by part number: 130004
|
| 21. |
84078667
|
[1] |
SHAFT
|
ZED
, Serial Range: -C491
|
| 21. |
84053189
|
[1] |
SHAFT
|
ZED
, Serial Range: -C491
|
| 22. |
43138
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
, Serial Range: -C491
|
| 23. |
84078480
|
[1] |
PLATE
|
ZED
|
| 23. |
84074341
|
[1] |
PLATE
|
ZED
|
