| 1. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 2. |
80140046
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 3. |
84074522
|
[1] |
COVER PLATE
|
ZED
|
| 4. |
80120044
|
[1] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 5. |
80370027
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370027
|
| 6. |
84074231
|
[2] |
ADJUSTING PLATE
|
ZED
|
| 7. |
80556885
|
[1] |
SHIM
|
ZED
Superseded by part number: 556885
|
| 8. |
80556831
|
[1] |
SHIM
|
ZED
Superseded by part number: 556831
|
| 9. |
84062534
|
[1] |
CLUTCH
|
ZED
, Serial Range: -C443 Superseded by part number: 84801473
|
| 9. |
84801473
|
[1] |
CLUTCH
|
ZED
, Start Serial: D444
|
| 10. |
84058691
|
[1] |
CHAIN,120HV, 82 Links x 38.1mm = 3124.2mm
|
ZED
(11)
|
| 11. |
84037875
|
[1] |
LINK,Chain
|
ZED
|
| 12. |
80394630
|
[1] |
WASHER
|
ZED
13 MM Superseded by part number: 86625256
|
| 13. |
80412605
|
[1] |
SCREW
|
ZED
M12 x 90 Superseded by part number: 412605
|
| 14. |
84074230
|
[1] |
BUSHING,60mm ID x 65mm OD x 60mm L
|
ZED
|
| 15. |
84078069
|
[1] |
HUB
|
ZED
|
| 16. |
80327911
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 327911
|
| 17. |
89839285
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 9839285
|
| 18. |
80043168
|
[1] |
BOLT
|
ZED
M16 x 40 Superseded by part number: 43168
|
| 19. |
80394631
|
[1] |
WASHER
|
ZED
17 MM Superseded by part number: 394631
|
| 20. |
100020
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 21. |
84100417
|
[1] |
COVER
|
ZED
|
| 22. |
84074232
|
[1] |
SEAL,90mm ID x 110mm OD x 8mm Thk
|
ZED
|
| 23. |
80301652
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 301652
|
| 24. |
84074234
|
[1] |
BEARING, ROLLER, CYL,60mm ID x 110mm OD x 28mm W
|
ZED
Superseded by part number: 428162
|
| 25. |
84078076
|
[1] |
BEARING HOUSING,75 mm ID x 130 mm OD x 64 mm
|
ZED
|
| 26. |
80552118
|
[1] |
SEAL
|
ZED
|
| 27. |
84074553
|
[1] |
SHAFT
|
ZED
|
| 27. |
84074691
|
[1] |
SHAFT
|
ZED
|
| 28. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 29. |
84053926
|
[1] |
HYD CONNECTOR
|
ZED
|
| 30. |
353308
|
[1] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 31. |
86508570
|
[1] |
BOLT,Hex, M6 x 80mm OAL, Cl 8.8
|
NH
|
| 32. |
84078078
|
[1] |
SHAFT
|
ZED
|
| 33. |
84074362
|
[1] |
DRIVEN SPROCKET
|
ZED
Z= 15 Superseded by part number: 47860193
|
| 33. |
84078584
|
[1] |
DRIVEN SPROCKET
|
ZED
Z= 17
|
| 34. |
80370003
|
[4] |
CIRCLIP
|
ZED
Superseded by part number: 370003
|
| 35. |
84814384
|
[2] |
BRACKET
|
ZED
|
| 36. |
84037939
|
[1] |
SHAFT
|
ZED
|
| 37. |
89706694
|
[1] |
NUT,M20, Cl 8
|
ZED
Superseded by part number: 9706694
|
| 38. |
84041797
|
[1] |
THREADED ROD
|
ZED
M20 x 360
|
| 39. |
84039507
|
[1] |
BRACKET
|
ZED
|
| 40. |
84041795
|
[1] |
WASHER,26mm ID x 82mm OD x 10mm Thk
|
ZED
|
| 41. |
84011609
|
[1] |
INSULATOR BLOCK
|
ZED
|
| 42. |
84041794
|
[1] |
SUPPORT
|
ZED
|
| 43. |
412180
|
[1] |
NUT,M20 x 2.5, Cl 8
|
ZED
Superseded by part number: 9672396
|
| 44. |
86629541
|
[9] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 45. |
84074520
|
[1] |
PROFILE
|
ZED
|
| 46. |
84037900
|
[1] |
SUPPORT
|
ZED
|
| 47. |
80140048
|
[4] |
WASHER
|
ZED
16.4 MM Superseded by part number: 140048
|
| 48. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 49. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8.2 MM Superseded by part number: 322358
|
| 50. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 51. |
853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 52. |
378246
|
[4] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 53. |
300388
|
[3] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
