| 1. |
84037903
|
[1] |
IDLER LEVER
|
ZED
|
| 2. |
80543835
|
[1] |
NUT
|
ZED
M40 x 1.5
|
| 3. |
80543836
|
[1] |
LOCK WASHER
|
ZED
40 MM
|
| 4. |
89838253
|
[1] |
WASHER
|
ZED
Superseded by part number: 9838253
|
| 5. |
84037898
|
[4] |
BUSHING,40mm ID x 60mm OD x 27.7mm L
|
ZED
|
| 6. |
84039090
|
[4] |
RING,40mm ID x 77.5mm OD x 0.3mm Thk
|
ZED
|
| 7. |
80210053
|
[4] |
BEARING ASSY
|
ZED
Superseded by part number: 87668909
|
| 8. |
80300633
|
[2] |
SNAP RING,M80, Int
|
ZED
Superseded by part number: 300633
|
| 9. |
84037899
|
[2] |
DRIVEN SPROCKET,12T
|
ZED
|
| 10. |
84078080
|
[1] |
SHAFT
|
ZED
|
| 11. |
80300637
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 300637
|
| 12. |
84000263
|
[1] |
ADJUSTING PLATE,76mm ID x 90mm OD x 0.25mm Thk
|
ZED
|
| 13. |
84074588
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 14. |
84074233
|
[1] |
SEAL,100mm ID x 135mm OD x 13mm Thk
|
ZED
SEALRING
|
| 15. |
80370014
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 370014
|
| 16. |
84074235
|
[1] |
SPHERICAL BEARING,75mm ID x 130mm OD x 31mm W
|
ZED
|
| 17. |
84074364
|
[1] |
BEARING HOUSING,95 mm ID x 152 mm OD x 76 mm
|
ZED
|
| 18. |
84004409
|
[1] |
SEAL,85mm ID x 100mm OD x 9mm Thk
|
ZED
|
| 19. |
84037935
|
[1] |
RING
|
ZED
|
| 20. |
80412274
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 412274
|
| 21. |
433754
|
[1] |
BEARING HOUSING
|
ZED
Superseded by part number: 85006156
|
| 22. |
80327911
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 327911
|
| 23. |
84014579
|
[1] |
WASHER,40mm ID x 50mm OD x 2mm Thk
|
ZED
|
| 24. |
86620027
|
[4] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 25. |
80552945
|
[2] |
BEARING ASSY
|
ZED
(48) Superseded by part number: 412441
|
| 26. |
84074554
|
[1] |
RING
|
ZED
|
| 27. |
80853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 28. |
89839285
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9839285
|
| 29. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 30. |
80140046
|
[1] |
WASHER
|
ZED
12.4 MM Superseded by part number: 140046
|
| 31. |
80120044
|
[1] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 32. |
89628065
|
[6] |
SCREW
|
ZED
M12 x 45, Serial Range: -C443 Superseded by part number: 9628065
|
| 33. |
84014578
|
[1] |
WASHER,40mm ID x 50mm OD x 1mm Thk
|
ZED
|
| 34. |
80370006
|
[4] |
SNAP RING
|
ZED
Superseded by part number: 370006
|
| 35. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 36. |
84817995
|
[1] |
GUARD
|
ZED
, Serial Range: -C383 Superseded by part number: 87656273
|
| 36. |
84800524
|
[1] |
GUARD
|
ZED
, Serial Range: -F384619 Superseded by part number: 87656273
|
| 36. |
87656273
|
[1] |
GUARD
|
ZED
, Start Serial: D620
|
| 37. |
86507486
|
[3] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 38. |
80322358
|
[3] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 39. |
89706690
|
[3] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 40. |
89706693
|
[3] |
SCREW,M12 x 60mm
|
ZED
M12 x 60, Serial Range: -C619 Superseded by part number: 9706693
|
| 40. |
84801647
|
[3] |
HEX SOC SCREW,M12 x 45mm, Cl 8.8
|
ZED
, Start Serial: D620 Superseded by part number: 14422321
|
| 41. |
80080679
|
[3] |
LOCK WASHER
|
ZED
Superseded by part number: 80679
|
| 42. |
89838358
|
[3] |
RING
|
ZED
, Serial Range: -C619 Superseded by part number: 9838358
|
| 43. |
80442203
|
[2] |
WASHER
|
ZED
Superseded by part number: 442203
|
| 44. |
84801355
|
[1] |
PLATE
|
ZED
L= 390 MM, Start Serial: D620
|
| 45. |
86511857
|
[2] |
SCREW,Phillips Drive, Flat HD, M8 x 20mm, Cl 4.8
|
ZED
, Start Serial: D620
|
| 46. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
, Start Serial: D620
|
| 47. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
, Start Serial: D620 Superseded by part number: 43362
|
| 48. |
563733
|
[1] |
COLLAR
|
ZED
|
