| 1. |
84042693
|
[1] |
FRAME
|
ZED
|
| 1. |
84068890
|
[1] |
FRAME
|
ZED
|
| 2. |
84042262
|
[1] |
COVER PLATE
|
ZED
|
| 3. |
89706685
|
[4] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 4. |
80140046
|
[2] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 5. |
80378245
|
[1] |
WASHER
|
ZED
12 MM Superseded by part number: 378245
|
| 6. |
80328754
|
[1] |
SCREW
|
ZED
M12 x 40 Superseded by part number: 328754
|
| 7. |
80334682
|
[1] |
BOLT
|
ZED
M12 x 50 Superseded by part number: 334682
|
| 8. |
80330413
|
[1] |
BANJO BOLT
|
ZED
Superseded by part number: 330413
|
| 9. |
84039445
|
[1] |
STOP
|
ZED
|
| 10. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 11. |
120103
|
[2] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 12. |
80300873
|
[1] |
ROLL PIN
|
ZED
Superseded by part number: 14607370
|
| 13. |
80321950
|
[1] |
PIN
|
ZED
M8 Superseded by part number: 86977792
|
| 14. |
80100037
|
[2] |
NUT,M10 x 1.5, Class 8
|
ZED
Superseded by part number: 100037
|
| 15. |
84041816
|
[1] |
U-BRACKET
|
ZED
|
| 15. |
84074007
|
[1] |
U-BRACKET
|
ZED
|
| 16. |
84041812
|
[1] |
SHIM,50mm OD x 1.5mm Thk
|
ZED
|
| 17. |
80394631
|
[4] |
WASHER
|
ZED
16 MM Superseded by part number: 394631
|
| 18. |
80120090
|
[4] |
SCREW
|
ZED
M16 x 50 Superseded by part number: 120090
|
| 19. |
84042694
|
[2] |
PIN
|
ZED
|
| 20. |
80140103
|
[2] |
WASHER
|
ZED
Superseded by part number: 140229
|
| 21. |
80370002
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 22. |
80536632
|
[2] |
BOLT
|
ZED
M10 x 60 Shear Superseded by part number: 536632
|
| 23. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 24. |
84807175
|
[2] |
HYDRAULIC CYLINDER,Double Acting, 20mm Rod, 235mm Stroke
|
ZED
|
| 25. |
80387792
|
[2] |
LOCK PIN
|
ZED
, Serial Range: -C535
|
| 25. |
87344037
|
[2] |
CLEVIS PIN,M12 x 90
|
ZED
, Start Serial: D536 Superseded by part number: 86639103
|
| 26. |
80130003
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 130003
|
| 27. |
84042703
|
[1] |
HOOK
|
ZED
|
| 28. |
80355988
|
[2] |
SPRING
|
ZED
Superseded by part number: 355988
|
| 29. |
84021756
|
[1] |
BANJO BOLT
|
ZED
M10 x 160
|
| 30. |
80325829
|
[1] |
SCREW
|
ZED
M10 x 45 Superseded by part number: 56614
|
| 31. |
80916612
|
[2] |
BREATHER
|
ZED
Superseded by part number: 916612
|
| 32. |
84026460
|
[2] |
SEAL KIT
|
ZED
|
| 33. |
26558
|
[1] |
WASHER,28.5mm ID x 45.2mm OD x 1.7mm Thk
|
NH
|
