| 1. |
84074241
|
[1] |
FRAME
|
ZED
|
| 1. |
84074378
|
[1] |
FRAME
|
ZED
|
| 2. |
84041706
|
[1] |
ROLLER
|
ZED
|
| 3. |
80370024
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370024
|
| 4. |
86629499
|
[1] |
BALL BEARING,20mm ID x 42mm OD x 12mm W
|
ZED
|
| 5. |
80300645
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 300645
|
| 6. |
84074190
|
[1] |
ROD
|
ZED
|
| 6. |
84056870
|
[1] |
ROD
|
ZED
|
| 7. |
80378245
|
[1] |
WASHER
|
ZED
13 MM Superseded by part number: 378245
|
| 8. |
80130045
|
[1] |
PIN
|
ZED
5 x 26 Superseded by part number: 130045
|
| 9. |
80151990
|
[1] |
SPRING
|
ZED
Superseded by part number: 151990
|
| 10. |
84056189
|
[1] |
PIN
|
ZED
|
| 11. |
84039459
|
[1] |
PIN,16mm OD
|
ZED
|
| 12. |
84043589
|
[1] |
SPRING
|
ZED
|
| 13. |
80140090
|
[1] |
WASHER
|
ZED
17 MM Superseded by part number: 140090
|
| 14. |
80333960
|
[1] |
ROLL PIN
|
ZED
Superseded by part number: 333960
|
| 15. |
80543043
|
[1] |
WASHER
|
ZED
13 MM Superseded by part number: 543043
|
| 16. |
80140046
|
[1] |
WASHER
|
ZED
12.4 MM Superseded by part number: 140046
|
| 17. |
89706687
|
[1] |
SCREW
|
ZED
M12 x 30 Superseded by part number: 9706687
|
| 18. |
84056505
|
[1] |
KNIFE
|
ZED
|
| 18. |
84058219
|
[23] |
KNIFE
|
ZED
|
| 19. |
84056868
|
[1] |
COVER PLATE
|
ZED
|
| 20. |
84042270
|
[1] |
CANVAS
|
ZED
|
| 20. |
84074192
|
[1] |
CANVAS,400mm W x 940mm L
|
ZED
|
| 21. |
89850761
|
[1] |
PIN
|
ZED
Superseded by part number: 9850761
|
| 22. |
84818466
|
[1] |
ROLL PIN,3mm OD x 26mm L, Slotted
|
ZED
3 x 26
|
| 23. |
80378246
|
[1] |
WASHER
|
ZED
17 MM Superseded by part number: 378246
|
| 24. |
80412685
|
[3] |
COTTER PIN
|
ZED
Superseded by part number: 412685
|
| 25. |
80140048
|
[1] |
WASHER
|
ZED
16.4 MM Superseded by part number: 140048
|
| 26. |
84807161
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25mm Rod, 120mm Stroke
|
ZED
(27), Serial Range: -C479
|
| 26. |
84461532
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25mm Rod, 120mm Stroke
|
ZED
(27,91), Start Serial: D480
|
| 27. |
84053275
|
[1] |
SEAL KIT
|
ZED
|
| 28. |
89501786
|
[1] |
PIN
|
ZED
|
| 29. |
80378247
|
[1] |
WASHER
|
ZED
21 MM Superseded by part number: 378247
|
| 30. |
80412686
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 412686
|
| 31. |
80386215
|
[1] |
HYD CONNECTOR
|
ZED
, Serial Range: -C479 Superseded by part number: 386215
|
| 31. |
84037257
|
[1] |
HYD CONNECTOR
|
ZED
, Start Serial: D480
|
| 32. |
80396162
|
[1] |
HYD CONNECTOR
|
ZED
, Serial Range: -C479 Superseded by part number: 396162
|
| 33. |
89706685
|
[2] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 34. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 35. |
80120041
|
[2] |
CARRIAGE BOLT
|
ZED
M10 x 25 Superseded by part number: 120041
|
| 36. |
84043965
|
[1] |
HYDRAULIC HOSE
|
ZED
, Serial Range: -C479
|
| 36. |
84043966
|
[1] |
HYDRAULIC HOSE
|
ZED
, Start Serial: D480
|
| 37. |
80292267
|
[1] |
BAND
|
ZED
|
| 38. |
80430356
|
[2] |
CLAMP
|
ZED
Superseded by part number: 430356
|
| 39. |
84814948
|
[1] |
SUPPORT
|
ZED
|
| 40. |
80353308
|
[1] |
NUT
|
ZED
M6 Superseded by part number: 353308
|
| 41. |
80120056
|
[1] |
SCREW
|
ZED
M6 x 50 Superseded by part number: 120056
|
| 42. |
84039315
|
[1] |
SHAFT
|
ZED
|
| 42. |
84074191
|
[1] |
SHAFT
|
ZED
|
| 43. |
80170019
|
[2] |
KEY
|
ZED
14 x 9 x 40 Superseded by part number: 170019
|
| 44. |
80412202
|
[3] |
LOCK PIN
|
ZED
Superseded by part number: 412202
|
| 45. |
84039463
|
[2] |
LEVER
|
ZED
|
| 46. |
80058821
|
[1] |
WASHER
|
ZED
Superseded by part number: 58821
|
| 47. |
84039452
|
[2] |
SUPPORT
|
ZED
|
| 48. |
80443076
|
[1] |
LOCK WASHER
|
ZED
46 MM Superseded by part number: 84814169
|
| 49. |
84005527
|
[1] |
WASHER,46mm ID x 70mm OD x 1mm Thk
|
ZED
46 MM
|
| 50. |
84068634
|
[1] |
LEVER
|
ZED
|
| 51. |
84068635
|
[1] |
PLATE
|
ZED
|
| 52. |
84041862
|
[1] |
CIRCLIP
|
ZED
|
| 53. |
84041936
|
[1] |
ROLLER,25mm OD x 15mm L
|
ZED
|
| 54. |
84043787
|
[1] |
PIN
|
ZED
Superseded by part number: 87652359
|
| 55. |
84607256
|
[1] |
TOOL
|
ZED
|
| 56. |
84038524
|
[1] |
SPRING,Compression, 1.26" OD x 13.39" L
|
ZED
|
| 57. |
84074189
|
[1] |
PROFILE
|
ZED
|
| 57. |
84068632
|
[1] |
PROFILE
|
ZED
|
| 58. |
84039309
|
[4] |
COVER PLATE
|
ZED
|
| 59. |
84039310
|
[2] |
HEX PLUG,44mm L
|
ZED
|
| 60. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 61. |
80380840
|
[2] |
PIN
|
ZED
46 x 60 x 1 Superseded by part number: 380840
|
| 62. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 63. |
84043973
|
[1] |
FRICTION WASHER,15mm ID x 21mm OD x 1.5mm Thk
|
ZED
|
| 65. |
84074330
|
[1] |
COVER PLATE
|
ZED
|
| 65. |
84045050
|
[1] |
COVER PLATE
|
ZED
|
| 66. |
84074329
|
[1] |
COVER PLATE
|
ZED
|
| 66. |
84045049
|
[1] |
COVER PLATE
|
ZED
|
| 67. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 68. |
80140045
|
[4] |
WASHER
|
ZED
Belleville, 10.2MM Superseded by part number: 140045
|
| 69. |
80372783
|
[1] |
KNOB
|
ZED
Superseded by part number: 372783
|
| 70. |
84814900
|
[2] |
WASHER,31mm ID x 48mm OD x 8mm Thk
|
ZED
|
| 71. |
84056934
|
[1] |
RACK
|
ZED
, Serial Range: -C535 Superseded by part number: 84801665
|
| 71. |
84801665
|
[1] |
RACK
|
ZED
, Start Serial: D536
|
| 72. |
80437424
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 437424
|
| 73. |
80043168
|
[4] |
BOLT
|
ZED
M16 x 40 Superseded by part number: 43168
|
| 74. |
80120044
|
[2] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 76. |
84042245
|
[1] |
FIXING PLATE
|
ZED
|
| 77. |
84042244
|
[1] |
FIXING PLATE
|
ZED
|
| 77. |
84074326
|
[1] |
FIXING PLATE
|
ZED
|
| 78. |
80140126
|
[1] |
WASHER
|
ZED
46 MM
|
| 79. |
84072937
|
[1] |
WIRE HARNESS
|
ZED
|
| 80. |
80445395
|
[1] |
RIVET,Pop, M4.8 x 18.1
|
ZED
Superseded by part number: 445395
|
| 81. |
84058863
|
[1] |
SENSOR
|
ZED
|
| 82. |
80323597
|
[10] |
STRAP
|
ZED
, Serial Range: -C499 Superseded by part number: 14560287
|
| 82. |
86566990
|
[10] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP, Start Serial: D500
|
| 83. |
89839372
|
[6] |
CLAMP
|
ZED
Superseded by part number: 9839372
|
| 84. |
NS
|
[1] |
NOT SERVICED
|
BAS
L=0.5 M
|
| 85. |
84058832
|
[1] |
CLIP
|
ZED
|
| 86. |
89512290
|
[2] |
RIVET
|
ZED
Superseded by part number: 9512290
|
| 87. |
84110678
|
[1] |
DIA KIT, HARVESTER
|
ATT
(18)
|
| 87. |
84110677
|
[1] |
DIA KIT, HARVESTER
|
ATT
(18)
|
| 88. |
920516
|
[1] |
GUIDE
|
ZED
|
| 89. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 90. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 91. |
84349899
|
[1] |
SERVICE KIT
|
ZED
|
