神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (07-003) - ROLLER ASSY (LOW) P/N 24100N4042F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4042F2 | [1] | TRACK ROLLER | KOB Superseded by part number: 24100N6505F1 |
| 3. | 2405P490 | [2] | BUSHING,50.2mm ID x 57mm OD x 50mm L | KOBID 50.2 x OD 57 x 50mm Long |
| 4. | 2418N2238D1 | [1] | COLLAR | KOB |
| 5. | 2418N2238D2 | [1] | COLLAR | KOB |
| 6. | 2418T12243 | [2] | RING | KOB |
| 7. | R45P0018D8 | [2] | SEAL | KOB |
| 8. | ZD11G04500 | [2] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 9. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 10. | 2413N468 | [1] | ROLLER | KOB |
| 11. | 2410N524 | [1] | SHAFT | KOB |
