神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (07-004) - ROLLER ASSY (UPPER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
616 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4038F2 | [1] | ROLLER | KOB Superseded by part number: LP64D01006F1 |
| 2. | 2410P773 | [1] | ROLLER SHAFT | KOB |
| 4. | 2418T17640 | [1] | PLATE | KOB |
| 6. | 2405T980 | [1] | BUSHING | KOB |
| 7. | R45P0018D2 | [1] | FLOAT | KOB Superseded by part number: 2445R360F1 |
| 8. | ZD11G05500 | [1] | O-RING,54.40mm ID x 60.60mm OD x 3.10mm | KOBID 54.40 ± 0.49 x OD 60mm |
| 9. | ZS23C08020 | [2] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 10. | ZR26X06000 | [1] | RING | KOBRetaining -- ID 60 x OD 64.2 x Th 2.0mm |
| 11. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 12. | 2413N467 | [1] | ROLLER | KOB Superseded by part number: LP64D01009P1 |
| 13. | 2418P23223 | [1] | COLLAR | KOB |
| 14. | 2414T4769 | [1] | COVER | KOB |
