凯斯零件查询(133) - CASE TWINE TIE RECTANGULAR BALER (1/57-12/62) (22) - PLUNGER STOP LATCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
B15901
|
[1] |
SHAFT - control plunger stop
|
|
| 2. |
B15906
|
[2] |
ANGLE - pivot shaft
|
|
| 3. |
T19468
|
[4] |
|
P
BOLT - (3/8" x 1" #3 plow w/nut) For ref. 2 angle
|
| 4. |
B15909
|
[1] |
SPACER - pivot shaft angle
|
|
| 5. |
213-6
|
[2] |
ADJUSTABLE CLEVIS,1/2"-20 x 3"
|
CAS
CLEVIS - plunger stop latch rod Superseded by part number: 87326432
|
| 6. |
141-6
|
[2] |
CLEVIS PIN,1/2" x 1.360"
|
CAS
PIN - clevis, stop latch rod Superseded by part number: 86636813
|
| 7. |
B15904
|
[1] |
ROD - plunger, stop latch
|
|
| 8. |
O6561AB
|
[1] |
|
CAS
PIN - clevis, plunger stop
|
| 9. |
B15898
|
[1] |
STOP - plunger
|
|
| 10. |
B15911
|
[1] |
WASHER - clipped, ref. 11 bolt
|
|
| 11. |
T19471
|
[1] |
PLOW BOLT
|
CAS
BOLT - (3/8" x 1-1/4" #3 plow w/nut) For ref. 12 angle Superseded by part number: 280136, 118-138
|
| 12. |
B15907
|
[1] |
ANGLE - latch stop
|
|
| 13. |
VT2155
|
[1] |
X
|
CAS
SPRING - plunger stop Superseded by part number: A30310
|
| 14. |
O2532AB
|
[1] |
|
CAS
CLIP - spring, plunger stop
|
