| 1. |
87044650
|
[1] |
LID
|
PA
Superseded by part number: 84134299
|
| 2. |
87656038
|
[1] |
TWINE BOX
|
PA
|
| 3. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
GTwine Clamp
|
| 5. |
86543545
|
[3] |
GUIDE
|
NH
|
| 6. |
9807894
|
[1] |
YOKE
|
PA
Superseded by part number: 86637611
|
| 7. |
86641563
|
[2] |
NEEDLE
|
NH
|
| 8. |
86629754
|
[1] |
LATCH
|
NH
|
| 11. |
9604396
|
[1] |
SUPPORT
|
PA
Superseded by part number: 86641498
|
| 15. |
132451
|
[1] |
PIN
|
PA
|
| 17. |
28114
|
[3] |
U-BOLT
|
NH
|
| 18. |
88542
|
[2] |
BOLT,Hex, 1/4"-20 x 1/2", Gr 5
|
NH
|
| 20. |
88011
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 22. |
374887
|
[2] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
NH
|
| 23. |
86521552
|
[7] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
NH
|
| 24. |
86566268
|
[4] |
LOCK BOLT,Prev Torque, Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
NH
|
| 27. |
280699
|
[1] |
HEX SOC SCREW,5/16" - 18 x 1 1/4"
|
WIN
|
| 28. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 29. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 30. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 31. |
80707
|
[4] |
WASHER,0.25" ID x 0.56" OD x 0.05" Thk
|
NH
|
| 32. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 33. |
87016
|
[2] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 34. |
27697
|
[1] |
WASHER,16.66mm ID x 27mm OD x 1.52mm Thk
|
NH
Superseded by part number: 87642936
|
| 35. |
65319
|
[8] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 36. |
86521605
|
[7] |
FLANGE NUT,5/16"-18, Cl 5
|
NH
|
| 37. |
86521609
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
NH
|
| 38. |
7770
|
[2] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 41. |
86629544
|
[2] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 43. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 44. |
87304
|
[6] |
NUT,#10-24
|
BEL
|
| 46. |
80755
|
[1] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
