| 1. |
86626039
|
[1] |
BEARING COVER
|
NH
Bearing, Tipping
|
| . . |
614-10020
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
SBX520 Superseded by part number: 43138
|
| . . |
814-10040
|
[2] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
SBX530 & SBX540 Superseded by part number: 120112
|
| . . |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 2. |
28114
|
[1] |
U-BOLT
|
NH
#10-24 x 1-15/16", Twine Guide
|
| . . |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| . . |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 3. |
86543545
|
[1] |
GUIDE
|
NH
Twine
|
| 4. |
86629487
|
[1] |
BEARING ASSY,34.99mm ID
|
NH
Includes: Ref. 5 & 6
|
| 5. |
9808112
|
[1] |
BALL BEARING,34.99mm ID x 71.88mm OD x 25mm W
|
NH
|
| 6. |
86577949
|
[1] |
SNAP RING,3.156", Int, #315
|
NH
|
| 7. |
86626042
|
[1] |
YOKE
|
NH
Superseded by part number: 84134301
|
| 8. |
29851
|
[1] |
PIN,15.87mm OD x 128.8mm L
|
NH
Superseded by part number: 84134303
|
| . . |
495-21019
|
[1] |
WASHER,#8
|
CAS
Superseded by part number: 280299, 72187261
|
| 9. |
573958
|
[1] |
BOLT
|
NH
Screw, Cap, HH, Drilled, G5, 3/4"-16 x 2-1/2"
|
| 10. |
516161
|
[1] |
WASHER
|
NH
25/32" I.D. x 2-3/8" O.D. x 1/4" Thick
|
| 11. |
86640860
|
[1] |
BUSHING
|
NH
Spacer
|
| 12. |
187426
|
[1] |
SHIM,.015" Thk
|
NH
|
| 13. |
578092
|
[1] |
WASHER,19.4mm ID x 47.6mm OD x 3.43mm Thk
|
NH
3/4", Hardened
|
| 14. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
Superseded by part number: 87340
|
| 15. |
425-1312
|
[1] |
SLOTTED NUT,3/4"-16, G5
|
CAS
Superseded by part number: 88886
|
| 16. |
86013355
|
[1] |
COTTER PIN
|
NH
Heat Treated, Plated, 3/16" x 1-1/2"
|
| 17. |
86629431
|
[1] |
ARM
|
NH
Pivot
|
| 18. |
86629430
|
[1] |
SUPPORT
|
NH
Ratchet
|
| 19. |
579577
|
[1] |
SPACER
|
NH
|
| 20. |
413-856
|
[1] |
BOLT,Hex, 1/2" - 13 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 9637417
|
| 21. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 22. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 23. |
86629408
|
[1] |
SUPPORT
|
NH
|
| . . |
614-12030
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| . . |
86513238
|
[4] |
LOCK WASHER,.515” ID x 1.070” OD x .120” TK
|
NH
Belleville, 1/2"
|
| 24. |
413-12112
|
[1] |
BOLT,Hex, 3/4" - 10 x 7", Gr 5
|
CAS
Superseded by part number: 280316
|
| 25. |
495-21081
|
[1] |
WASHER,3/4"
|
CAS
Superseded by part number: 86511191
|
| 26. |
788355
|
[1] |
SPRING
|
NH
SBX520
|
| 26. |
115150
|
[1] |
SPRING
|
NH
SBX530 & SBX540
|
| 27. |
232-41412
|
[1] |
LOCK NUT,3/4"-10, GC
|
CAS
Superseded by part number: 280375
|
| 28. |
280534
|
[1] |
CARRIAGE BOLT,#3, 3/8" - 16 x 2", Gr 5
|
NH
|
| 29. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 30. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 31. |
167444
|
[2] |
SPACER
|
NH
SBX530 & SBX540
|
