凯斯零件查询(SBX520) - CASE IH SQUARE BALER (1/02-8/08) (013) - POWER TAKE OFF, REAR, SBX520 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86629484
|
[1] |
INNER SHIELD
|
NH
Metal Shield Superseded by part number: 87045660, 87045659
|
| 1. |
87045659
|
[1] |
HALF SHAFT
|
PA
Plastic Shield
|
| 2. |
86629485
|
[1] |
PTO
|
NH
Shaft, Metal Shield Superseded by part number: 87045660, 87045659
|
| 2. |
87045660
|
[1] |
PTO
|
PA
Plastic Shield
|
| 3. |
859335
|
[1] |
TUBE,2.25" OD x 41.00" L
|
NH
Inner
|
| 4. |
56760
|
[2] |
SNAP RING
|
NH
|
| 5. |
56801
|
[2] |
THRUST WASHER
|
NH
Superseded by part number: 613437R1
|
| 6. |
579113
|
[2] |
BUSHING,2.082" ID x 2.804" OD x 0.375"
|
NH
Superseded by part number: 850432
|
| 7. |
754317
|
[1] |
NYLON BEARING
|
CAS
Bearing
|
| 7. |
764201
|
[1] |
SEAL,50.93mm ID x 58.19mm OD x 6.35mm Thk
|
GI
Superseded by part number: 80764201, 80764201, NLS
|
| 8. |
228147
|
[1] |
OUTER SHIELD
|
NH
Metal Shield Superseded by part number: 87048216, 80764201, 87048274, 87048215, 764200
|
| 8. |
87048215
|
[1] |
OUTER SHIELD
|
PA
Plastic Shield
|
| 9. |
86977074
|
[1] |
SHIELD
|
NH
Metal Shield Superseded by part number: 87048216
|
| 9. |
87048216
|
[1] |
SHIELD
|
PA
Plastic Shield
|
| 10. |
859333
|
[1] |
PTO SHAFT
|
NH
Yoke
|
| 11. |
29214
|
[1] |
BEARING ASSY
|
NH
Superseded by part number: 84355326
|
| 12. |
376219R1
|
[1] |
SNAP RING,1.653, Int, #165
|
IH
Superseded by part number: 183442
|
| 13. |
44680
|
[1] |
BALL BEARING,20mm ID x 42mm OD x 12mm W
|
NH
Superseded by part number: 84330089
|
| 14. |
261342
|
[1] |
YOKE
|
NH
|
| 15. |
184317
|
[1] |
BUSHING,34.88mm ID x 38.13mm OD x 33.3mm L
|
NH
|
| 16. |
86629486
|
[2] |
DOG
|
NH
Clutch
|
| 17. |
46789
|
[2] |
PIN,12.7mm OD x 41.27mm L
|
NH
|
| 18. |
432-828
|
[2] |
COTTER PIN,1/8" x 1 3/4"
|
CAS
Superseded by part number: 87673
|
| 19. |
219-87
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 20. |
849472
|
[2] |
DANGER DECAL
|
NH
|
| 21. |
87048274
|
[1] |
BEARING COVER
|
PA
|
| 22. |
849471
|
[1] |
DANGER DECAL
|
NH
|
