纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-014[00]) - HYDRAULIC TANK ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
678 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT33H00048F1 | [1] | Hyd. | |
| 1. | YT33H00047F1 | [1] | TANK | KOBAssy., Hyd. |
| 2. | YT33H01100P1 | [1] | COVER | KOB |
| 3. | YT33H01101P1 | [1] | COVER | KOB |
| 4. | YT50V00003F1 | [1] | STRAINER ELEMENT | KOBSuction |
| 5. | YT50V00003S001 | [1] | STRAINER ELEMENT | KOBSuction |
| 6. | 2446R110S2 | [1] | HOLDER | KOB |
| 7. | YT50V00003S003 | [1] | BOLT | KOB |
| 8. | ZN11C10008 | [2] | NUT | KOB Superseded by part number: ZN18C10008 |
| 9. | 2446R110S6 | [1] | SPRING | KOB |
| 10. | YN57V00004F1 | [1] | BREATHER | KOBAssy. Superseded by part number: YN57V00010F1 |
| 11. | YN57V00004S002 | [1] | ELEMENT | KOBFilter Superseded by part number: YN57V00010S002 |
| 12. | 2446U260S10 | [1] | NUT | KOB |
| 13. | 2446U260S8 | [1] | PACKING | KOB |
| 14. | YN58S00009F1 | [1] | GAUGE | KOBLevel, Oil |
| 15. | YR52V01004F2 | [1] | ELEMENT | KOBFilter |
| 16. | YR52V01001S002 | [1] | RUBBER JOINT | KOB |
| 17. | YR21V00001P1 | [1] | VALVE | KOBCheck |
| 18. | YR52V01001S004 | [1] | SPRING | KOB |
| 19. | YR52V01003P2 | [2] | HYDRAULIC OIL FILTER | KOBElement |
| 20. | ZE72X08000 | [1] | PLUG | KOB |
| 21. | ZM73C10025 | [12] | BOLT,M10x25mm - Course Thread | KOBSems |
| 22. | YN33H01304P1 | [4] | BOLT | KOBSems |
| 23. | ZD11G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOB |
| 24. | ZD11G15500 | [1] | O-RING,154.30mm ID x 165.70mm OD x 5.70mm | KOB |
| 25. | YT33H00046P1 | [1] | TANK | KOB |
| 26. | YT33H00036F1 | [1] | TANK | KOBInstal, Hyd. |
| 27. | ZS18C16050 | [4] | SCREW,Hex, M16 x 50mm | KOBCap |
| 28. | ZW16H16000 | [4] | WASHER | KOB |
| 29. | LE33H01017D1 | [3] | SHIM | KOB(1.0) |
| 30. | LS21C01093DH | [1] | TRIM | KOB |
| 31. | LS21C01093DM | [1] | GASKET | KOB |
| . . | YR52V01004R400 | [1] | REPAIR KIT | KOBConsists Of Item: 16(1), 23(1), 19(2) |
