纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-015[00]) - POWER TAKE OFF ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30P00004F1 | [1] | | |
| 1. | YT30P00003F1 | [1] | PTO | KOBAssy. |
| 2. | YT30P01007P1 | [1] | BRACKET | KOB |
| 3. | LF30P01001F1 | [1] | COUPLING | KOBAssy. |
| 4. | LF30P01001S001 | [1] | COUPLING | KOB |
| 5. | 2418U128S5 | [6] | SCREW | KOBCap |
| 6. | ZP26D05010 | [9] | PIN | KOBSpring |
| 7. | YT30P01009P1 | [1] | HUB | KOB |
| 8. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBscrew |
| 9. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBCap |
| 10. | ZM73C10045 | [4] | BOLT,M10x45mm - Course Thread | KOBSems |
| 11. | YT10V00023F1 | [1] | HYDRAULIC PUMP | KOBAssy. |
