纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[05]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
718 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT30V00048F1 | [2] | VALVE | KOBControl |
| 2. | ZD12P00800 | [3] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 3. | ZS23C08060 | [4] | SCREW,Hex Socket Head, M8 x 60mm | KOBCap |
| 4. | 2436U1514S38 | [1] | O-RING | KOB |
| 5. | YT30V00039S019 | [1] | FLANGE | KOB |
| 6. | YT22V00016F1 | [8] | VALVE, PRESSURE RELI | KOBEF |
| 7. | YT22V00016F2 | [2] | VALVE, PRESSURE RELI | KOBEF |
| 8. | YT30V00039S024 | [18] | O-RING | KOB |
| 9. | YT30V00039S027 | [2] | PLUG | KOB |
| 10. | YT30V00039S028 | [1] | SPOOL | KOB |
| 11. | YT30V00039S029 | [3] | SPRING | KOB |
| 12. | YT30V00039S030 | [3] | CHECK CONTROL | KOBPoppet |
| 13. | YT30V00039S031 | [3] | SPRING | KOB |
| 14. | YT30V00039S032 | [3] | CAP | KOB |
| 15. | YT30V00039S033 | [8] | CAP | KOB |
| 16. | YT30V00039S034 | [4] | CAPTIVE WASHER SCREW | KOB |
| 17. | YT30V00039S044 | [2] | SPRING | KOB |
| 18. | YT30V00039S045 | [2] | POPPET | KOB |
| 19. | YT22V00012S004 | [2] | PLUG | KOB |
| 22. | ZD12P01100 | [24] | O-RING | KOB |
| 23. | YT30V00039S080 | [2] | CHECK CONTROL | KOBPoppet |
| 24. | YT30V00039S081 | [2] | CAP | KOB |
| 25. | YT30V00039S082 | [2] | SPRING | KOB |
| 26. | ZD11P01000 | [2] | O-RING | KOB |
| 27. | ZD85P01000 | [4] | RING, SNAP | KOBSNAP RING Back-Up |
| 28. | 2436U1309S41 | [9] | CAP | KOB |
| 30. | YT30V00039S093 | [1] | SPOOL | KOB |
| 31. | YT30V00039S094 | [1] | SPRING | KOB |
| 32. | YT30V00047S094 | [1] | SPOOL | KOB |
