纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[07]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT30V00050F1 | [1] | SELECTOR | KOB |
| 2. | YT22V00017F1 | [1] | HYDRAULIC VALVE | KOBRelief |
| 3. | YT22V00016F1 | [8] | VALVE, PRESSURE RELI | KOBEF |
| 4. | ZS23C08070 | [4] | SCREW,Hex Socket Head, M8 x 70mm | KOBCap |
| 5. | ZD12P00800 | [15] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 6. | ZD12P01800 | [27] | O-RING | KOB |
| 7. | ZD12P01000 | [2] | O-RING | KOB |
| 8. | ZD12P01400 | [1] | O-RING | KOB |
| 9. | ZD12P02200 | [2] | O-RING | KOB |
| 10. | YT30V00042S022 | [6] | CAP | KOB |
| 11. | 2436U1309S29 | [11] | CAP | KOB |
| 12. | ZD12P02100 | [1] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOB |
