纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-021[02]) - HYDRAULIC LINES, UPPER (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
421 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZS18C10080 | [4] | SCREW,Hex, M10 x 80mm | KOBCap |
| 2. | HH25R08006G4 | [1] | HYD CONNECTOR | KOB |
| 3. | YT03H01054P1 | [5] | CONNECTION | KOB |
| 4. | ZA28F12006 | [1] | HYD CONNECTOR | KOB |
| 5. | ZA28F18008 | [5] | HYD CONNECTOR | KOB |
| 6. | ZA29F18008 | [1] | HYD CONNECTOR | KOB |
| 7. | ZA38F18008 | [3] | HYD CONNECTOR | SMElbow |
| 8. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| 9. | YT03H01127P1 | [2] | BUSHING | KOB |
| 10. | ZD12P01800 | [9] | O-RING | KOB |
| 11. | YT03H01125P1 | [2] | PLATE | KOB |
| 12. | LF03H01030P1 | [1] | PLATE | KOB |
| 13. | YT03H01135P1 | [1] | BRACKET, SUPPORTING | KOB |
| 14. | LF03H01023D1 | [1] | RUBBER SEAL | KOB |
| 15. | LF03H01023D2 | [2] | RUBBER SEAL | KOB |
| 16. | ZW16H10000 | [5] | WASHER | KOB |
| 17. | 2444Z3713 | [1] | HYD CONNECTOR | KOB |
| 18. | HH25R08008G6 | [1] | HYD CONNECTOR | KOB |
| 19. | ZD12P01400 | [2] | O-RING | KOB |
| 20. | YT03H01028P1 | [2] | CONNECTION | KOB |
| 21. | 2444Z2449 | [1] | HYD CONNECTOR | KOB |
| 22. | ZA38F12006 | [1] | 90 ELBOW | KOB |
